Sunon
- Founded in 1980, Sunonwealth Electric Machine Industry Company Limited has always adhered to the business philosophy of “Brand, Innovation, and Value”. Step by step, it has now become a global leader in the fields of precision motors, mini fans, and thermal modules.
Sunon designs and manufactures a full range of high-performance fans, blowers and coolers. The company is committed to supplying the widest selection of quality axial fans and blowers, which includes DC brushless fans, micro DC blowers, CPU coolers, graphic card coolers and AC fans. Sunon manufactures some of the industries smallest, thinnest and most power efficient fans and blowers in sizes ranging from 0.315 inches (8mm) to 10 inches (250mm) in outside diameter and from 0.157 inches (4mm) to 1.5 inches (38mm) in thickness. More than 700 different models are available to customers.
Sunon’s fans, blowers and coolers find application in a wide range of industries and products. The company’s products are used in many of the world’s most popular personal computers, workstations, servers, networking hubs, scanners, printers and more. In office equipment, Sunon products can be found in copiers, fax machines and projectors. Sunon is equally at home in the appliance market, with applications for refrigerators, air cleaners and air heaters. Other markets include medical, laboratory and manufacturing equipment, as well as vending machines.
Part Number
Manufacturer
Description
Unit Price
In Stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 30mm L x 30mm H
Width : 6.90mm
Air Flow : 4.9 CFM (0.137m鲁/min)
Static Pressure : 0.140 in H2O (34.9 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart, Speed Sensor (Tach)
Noise : 28.0 dB(A)
Power (Watts) : 560mW
RPM : 9500 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.013 lb (5.9g)
0
322 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 30mm L x 30mm H
Width : 6.90mm
Air Flow : 3.7 CFM (0.104m鲁/min)
Static Pressure : 0.090 in H2O (22.4 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 24.0 dB(A)
Power (Watts) : 360mW
RPM : 7500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.013 lb (5.9g)
0
6401 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 30mm L x 30mm H
Width : 10.00mm
Air Flow : 5.5 CFM (0.154m鲁/min)
Static Pressure : 0.150 in H2O (37.3 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 23.0 dB(A)
Power (Watts) : 600mW
RPM : 9500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.019 lb (8.62g)
0
13588 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 30mm L x 30mm H
Width : 10.00mm
Air Flow : 5.5 CFM (0.154m鲁/min)
Static Pressure : 0.150 in H2O (37.3 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart, Speed Sensor (Tach)
Noise : 23.0 dB(A)
Power (Watts) : 600mW
RPM : 9500 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.019 lb (8.62g)
0
474 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 30mm L x 30mm H
Width : 10.00mm
Air Flow : 4.6 CFM (0.129m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 20.0 dB(A)
Power (Watts) : 380mW
RPM : 8000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.019 lb (8.62g)
0
1933 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 30mm L x 30mm H
Width : 10.00mm
Air Flow : 5.5 CFM (0.154m鲁/min)
Static Pressure : 0.150 in H2O (37.3 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 23.0 dB(A)
Power (Watts) : 580mW
RPM : 9500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.019 lb (8.62g)
0
9698 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 30mm L x 30mm H
Width : 10.00mm
Air Flow : 5.5 CFM (0.154m鲁/min)
Static Pressure : 0.150 in H2O (37.3 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart, Speed Sensor (Tach)
Noise : 23.0 dB(A)
Power (Watts) : 580mW
RPM : 9500 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.019 lb (8.62g)
0
1518 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 30mm L x 30mm H
Width : 10.00mm
Air Flow : 4.6 CFM (0.129m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 20.0 dB(A)
Power (Watts) : 480mW
RPM : 8000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.019 lb (8.62g)
0
1059 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 30mm L x 30mm H
Width : 15.00mm
Air Flow : 6.0 CFM (0.168m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 27.0 dB(A)
Power (Watts) : 650mW
RPM : 8500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.029 lb (13.15g)
0
2184 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 35mm L x 35mm H
Width : 10.00mm
Air Flow : 7.0 CFM (0.196m鲁/min)
Static Pressure : 0.180 in H2O (44.8 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 28.0 dB(A)
Power (Watts) : 750mW
RPM : 9500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.024 lb (10.89g)
0
2298 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 35mm L x 35mm H
Width : 10.00mm
Air Flow : 6.5 CFM (0.182m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 22.0 dB(A)
Power (Watts) : 380mW
RPM : 7500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.024 lb (10.89g)
0
6947 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MC
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 35mm L x 35mm H
Width : 10.00mm
Air Flow : 6.5 CFM (0.182m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart, Speed Sensor (Tach)
Noise : 22.0 dB(A)
Power (Watts) : 380mW
RPM : 7500 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.023 lb (10.43g)
0
81 in stock
