- Discrete Semiconductor Products
- Transistors - IGBTs - Single
Part Number
Manufacturer
Description
Unit Price
In Stock
NGTB25N120SWG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 50A
Current - Collector Pulsed (Icm) : 100A
Vce(on) (Max) @ Vge, Ic : 2.4V @ 15V, 25A
Power - Max : 385W
Switching Energy : 1.95mJ (on), 600µJ (off)
Input Type : Standard
Gate Charge : 178nC
Td (on/off) @ 25°C : 87ns/179ns
Test Condition : 600V, 25A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 154ns
Operating Temperature : -55°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247-3
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 50A
Current - Collector Pulsed (Icm) : 100A
Vce(on) (Max) @ Vge, Ic : 2.4V @ 15V, 25A
Power - Max : 385W
Switching Energy : 1.95mJ (on), 600µJ (off)
Input Type : Standard
Gate Charge : 178nC
Td (on/off) @ 25°C : 87ns/179ns
Test Condition : 600V, 25A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 154ns
Operating Temperature : -55°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247-3
0
60 in stock
NGTB30N120FL2WG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 2.3V @ 15V, 30A
Power - Max : 452W
Switching Energy : 2.6mJ (on), 700µJ (off)
Input Type : Standard
Gate Charge : 220nC
Td (on/off) @ 25°C : 98ns/210ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 240ns
Operating Temperature : -55°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 2.3V @ 15V, 30A
Power - Max : 452W
Switching Energy : 2.6mJ (on), 700µJ (off)
Input Type : Standard
Gate Charge : 220nC
Td (on/off) @ 25°C : 98ns/210ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 240ns
Operating Temperature : -55°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
0
54 in stock
NGTB30N120IHLWG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Obsolete
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 320A
Vce(on) (Max) @ Vge, Ic : 2.2V @ 15V, 30A
Power - Max : 260W
Switching Energy : 1mJ (off)
Input Type : Standard
Gate Charge : 420nC
Td (on/off) @ 25°C : -/360ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
Packaging : Tube
Series : -
Part Status : Obsolete
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 320A
Vce(on) (Max) @ Vge, Ic : 2.2V @ 15V, 30A
Power - Max : 260W
Switching Energy : 1mJ (off)
Input Type : Standard
Gate Charge : 420nC
Td (on/off) @ 25°C : -/360ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
0
100 in stock
NGTB30N120IHRWG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 2.5V @ 15V, 30A
Power - Max : 384W
Switching Energy : 700µJ (off)
Input Type : Standard
Gate Charge : 225nC
Td (on/off) @ 25°C : -/230ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -40°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 2.5V @ 15V, 30A
Power - Max : 384W
Switching Energy : 700µJ (off)
Input Type : Standard
Gate Charge : 225nC
Td (on/off) @ 25°C : -/230ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -40°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
0
90 in stock
NGTB30N120IHSWG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Obsolete
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 200A
Vce(on) (Max) @ Vge, Ic : 2.4V @ 15V, 30A
Power - Max : 192W
Switching Energy : 1mJ (off)
Input Type : Standard
Gate Charge : 220nC
Td (on/off) @ 25°C : -/210ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
Packaging : Tube
Series : -
Part Status : Obsolete
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 200A
Vce(on) (Max) @ Vge, Ic : 2.4V @ 15V, 30A
Power - Max : 192W
Switching Energy : 1mJ (off)
Input Type : Standard
Gate Charge : 220nC
Td (on/off) @ 25°C : -/210ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
0
100 in stock
NGTB30N120L2WG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 1.9V @ 15V, 30A
Power - Max : 534W
Switching Energy : 4.4mJ (on), 1.4mJ (off)
Input Type : Standard
Gate Charge : 310nC
Td (on/off) @ 25°C : 116ns/285ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 450ns
Operating Temperature : -55°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 1.9V @ 15V, 30A
Power - Max : 534W
Switching Energy : 4.4mJ (on), 1.4mJ (off)
Input Type : Standard
Gate Charge : 310nC
Td (on/off) @ 25°C : 116ns/285ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 450ns
Operating Temperature : -55°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
0
60 in stock
NGTB30N120LWG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Obsolete
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 240A
Vce(on) (Max) @ Vge, Ic : 2.2V @ 15V, 30A
Power - Max : 560W
Switching Energy : 4.4mJ (on), 1mJ (off)
Input Type : Standard
Gate Charge : 420nC
Td (on/off) @ 25°C : 136ns/360ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
Packaging : Tube
Series : -
Part Status : Obsolete
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1200V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 240A
Vce(on) (Max) @ Vge, Ic : 2.2V @ 15V, 30A
Power - Max : 560W
Switching Energy : 4.4mJ (on), 1mJ (off)
Input Type : Standard
Gate Charge : 420nC
Td (on/off) @ 25°C : 136ns/360ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
0
100 in stock
NGTB30N135IHR1WG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1350V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 3V @ 15V, 30A
Power - Max : 394W
Switching Energy : 630µA (off)
Input Type : Standard
Gate Charge : 220nC
Td (on/off) @ 25°C : -/200ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -40°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247-3
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1350V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 3V @ 15V, 30A
Power - Max : 394W
Switching Energy : 630µA (off)
Input Type : Standard
Gate Charge : 220nC
Td (on/off) @ 25°C : -/200ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -40°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247-3
0
87 in stock
NGTB30N135IHRWG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1350V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 2.65V @ 15V, 30A
Power - Max : 394W
Switching Energy : 850µJ (off)
Input Type : Standard
Gate Charge : 234nC
Td (on/off) @ 25°C : -/250ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -40°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 1350V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 2.65V @ 15V, 30A
Power - Max : 394W
Switching Energy : 850µJ (off)
Input Type : Standard
Gate Charge : 234nC
Td (on/off) @ 25°C : -/250ns
Test Condition : 600V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -40°C ~ 175°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
0
90 in stock
NGTB30N60FLWG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Obsolete
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 600V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 1.9V @ 15V, 30A
Power - Max : 250W
Switching Energy : 700µJ (on), 280µJ (off)
Input Type : Standard
Gate Charge : 170nC
Td (on/off) @ 25°C : 83ns/170ns
Test Condition : 400V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 72ns
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
Packaging : Tube
Series : -
Part Status : Obsolete
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 600V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 1.9V @ 15V, 30A
Power - Max : 250W
Switching Energy : 700µJ (on), 280µJ (off)
Input Type : Standard
Gate Charge : 170nC
Td (on/off) @ 25°C : 83ns/170ns
Test Condition : 400V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 72ns
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
0
100 in stock
NGTB30N60FWG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Obsolete
IGBT Type : Trench
Voltage - Collector Emitter Breakdown (Max) : 600V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 1.7V @ 15V, 30A
Power - Max : 167W
Switching Energy : 650µJ (on), 650µJ (off)
Input Type : Standard
Gate Charge : 170nC
Td (on/off) @ 25°C : 81ns/190ns
Test Condition : 400V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 72ns
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
Packaging : Tube
Series : -
Part Status : Obsolete
IGBT Type : Trench
Voltage - Collector Emitter Breakdown (Max) : 600V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 120A
Vce(on) (Max) @ Vge, Ic : 1.7V @ 15V, 30A
Power - Max : 167W
Switching Energy : 650µJ (on), 650µJ (off)
Input Type : Standard
Gate Charge : 170nC
Td (on/off) @ 25°C : 81ns/190ns
Test Condition : 400V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 72ns
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
0
100 in stock
NGTB30N60IHLWG
Aptina / ON Semiconductor
Manufacturer : ON Semiconductor
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 600V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 150A
Vce(on) (Max) @ Vge, Ic : 2.3V @ 15V, 30A
Power - Max : 250W
Switching Energy : 280µJ (off)
Input Type : Standard
Gate Charge : 130nC
Td (on/off) @ 25°C : 70ns/140ns
Test Condition : 400V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 400ns
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
Packaging : Tube
Series : -
Part Status : Active
IGBT Type : Trench Field Stop
Voltage - Collector Emitter Breakdown (Max) : 600V
Current - Collector (Ic) (Max) : 60A
Current - Collector Pulsed (Icm) : 150A
Vce(on) (Max) @ Vge, Ic : 2.3V @ 15V, 30A
Power - Max : 250W
Switching Energy : 280µJ (off)
Input Type : Standard
Gate Charge : 130nC
Td (on/off) @ 25°C : 70ns/140ns
Test Condition : 400V, 30A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 400ns
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247
0
197 in stock
New Original Stock
Competitive Prices
One-stop
Customer Service
Contact Weijie
- sales@ynnelec.com
- jay@ynnelec.com
- 1132 Nanguang Jiejia Building, No. 3037 Shennan Middle Road, Futian District, Shenzhen
Customer service
Copyright © 2025 Ynnelec. All rights reserved.
webdesign www.wzdzkf.com
Powered by www.wzdzkf.com
