Laird Thermal Materials
- Laird Thermal Systems is an end-to-end solutions partner offering continuous access to OEMs through its industry leading component and application expertise. An engineering force utilizing the broadest, vertically integrated thermal management product range in the industry, Laird facilitates customer technology development by providing cutting edge solutions coupled with the ability to qualify, manufacture and service globally.
Part Number
Manufacturer
Description
Unit Price
In Stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : OptoTEC™
Part Status : Active
Outline L x W x H : 3.40mm x 3.40mm x 2.44mm
Qmax @ Th : 0.2W @ 25°C
Delta Tmax @ Th : 67°C @ 25°C
Current - Max : 0.8A
Voltage - Max : 0.5V
Resistance : 520 mOhms
Operating Temperature : 80°C
Features : Lead Wires, Non-Sealed
0
25 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : OptoTEC™
Part Status : Active
Outline L x W x H : 3.40mm x 3.40mm x 2.79mm
Qmax @ Th : 0.2W @ 25°C
Delta Tmax @ Th : 67°C @ 25°C
Current - Max : 0.8A
Voltage - Max : 0.5V
Resistance : 520 mOhms
Operating Temperature : 80°C
Features : Lead Wires, Non-Sealed
0
100 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : CP
Part Status : Active
Outline L x W x H : 29.72mm x 14.86mm x 3.33mm
Qmax @ Th : 20.4W @ 25°C
Delta Tmax @ Th : 68°C @ 25°C
Current - Max : 8.7A
Voltage - Max : 4.0V
Resistance : 430 mOhms
Operating Temperature : 80°C
Features : Lead Wires, Sealed - Epoxy
0
14 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : ThermaTEC™
Part Status : Active
Outline L x W x H : 34.00mm x 30.00mm x 3.33mm
Qmax @ Th : 40.7W @ 25°C
Delta Tmax @ Th : 63°C @ 25°C
Current - Max : 8.5A
Voltage - Max : 8.1V
Resistance : 880 mOhms
Operating Temperature : 175°C
Features : Lead Wires, Sealed - Silicone RTV
0
79 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : ThermaTEC™
Part Status : Active
Outline L x W x H : 34.00mm x 30.00mm x 3.33mm
Qmax @ Th : 40.7W @ 25°C
Delta Tmax @ Th : 63°C @ 25°C
Current - Max : 8.5A
Voltage - Max : 8.1V
Resistance : 880 mOhms
Operating Temperature : 175°C
Features : Lead Wires, Non-Sealed
0
249 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : CP
Part Status : Active
Outline L x W x H : 22.60mm x 22.60mm x 3.58mm
Qmax @ Th : 14.4W @ 25°C
Delta Tmax @ Th : 67°C @ 25°C
Current - Max : 3.0A
Voltage - Max : 8.6V
Resistance : 2.43 Ohms
Operating Temperature : 80°C
Features : Lead Wires, Sealed - Silicone RTV
0
20 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : CP
Part Status : Active
Outline L x W x H : 22.60mm x 22.60mm x 3.58mm
Qmax @ Th : 14.4W @ 25°C
Delta Tmax @ Th : 67°C @ 25°C
Current - Max : 3.0A
Voltage - Max : 8.6V
Resistance : 2.43 Ohms
Operating Temperature : 80°C
Features : Lead Wires, Non-Sealed
0
143 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : OptoTEC™
Part Status : Active
Outline L x W x H : 12.20mm x 6.00mm x 1.62mm
Qmax @ Th : 4.5W @ 25°C
Delta Tmax @ Th : 67°C @ 25°C
Current - Max : 1.9A
Voltage - Max : 4.0V
Resistance : 1.92 Ohms
Operating Temperature : 80°C
Features : Lead Wires, Non-Sealed
0
35 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : OptoTEC™
Part Status : Active
Outline L x W x H : -
Qmax @ Th : 4.5W @ 25°C
Delta Tmax @ Th : 67°C @ 25°C
Current - Max : 1.9A
Voltage - Max : 4.0V
Resistance : 1.92 Ohms
Operating Temperature : 80°C
Features : Lead Wires, Sealed - Epoxy
0
100 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : OptoTEC™
Part Status : Active
Outline L x W x H : 12.20mm x 6.00mm x 1.65mm
Qmax @ Th : 4.5W @ 25°C
Delta Tmax @ Th : 67°C @ 25°C
Current - Max : 1.9A
Voltage - Max : 4.0V
Resistance : 1.92 Ohms
Operating Temperature : 80°C
Features : Lead Wires, Sealed - Silicone RTV
0
10 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : OptoTEC™
Part Status : Active
Outline L x W x H : 12.20mm x 6.00mm x 1.62mm
Qmax @ Th : 4.5W @ 25°C
Delta Tmax @ Th : 67°C @ 25°C
Current - Max : 1.9A
Voltage - Max : 4.0V
Resistance : 1.92 Ohms
Operating Temperature : 80°C
Features : Lead Wires, Non-Sealed
0
40 in stock
Laird Thermal Materials
Manufacturer : Laird Technologies - Engineered Thermal Solutions
Series : CP
Part Status : Active
Outline L x W x H : 24.60mm x 24.60mm x 3.10mm
Qmax @ Th : 22.6W @ 25°C
Delta Tmax @ Th : 67°C @ 25°C
Current - Max : 2.6A
Voltage - Max : 14.4V
Resistance : 5.10 Ohms
Operating Temperature : 80°C
Features : Lead Wires, Sealed - Silicone RTV
0
274 in stock
