Sunon
- Founded in 1980, Sunonwealth Electric Machine Industry Company Limited has always adhered to the business philosophy of “Brand, Innovation, and Value”. Step by step, it has now become a global leader in the fields of precision motors, mini fans, and thermal modules.
Sunon designs and manufactures a full range of high-performance fans, blowers and coolers. The company is committed to supplying the widest selection of quality axial fans and blowers, which includes DC brushless fans, micro DC blowers, CPU coolers, graphic card coolers and AC fans. Sunon manufactures some of the industries smallest, thinnest and most power efficient fans and blowers in sizes ranging from 0.315 inches (8mm) to 10 inches (250mm) in outside diameter and from 0.157 inches (4mm) to 1.5 inches (38mm) in thickness. More than 700 different models are available to customers.
Sunon’s fans, blowers and coolers find application in a wide range of industries and products. The company’s products are used in many of the world’s most popular personal computers, workstations, servers, networking hubs, scanners, printers and more. In office equipment, Sunon products can be found in copiers, fax machines and projectors. Sunon is equally at home in the appliance market, with applications for refrigerators, air cleaners and air heaters. Other markets include medical, laboratory and manufacturing equipment, as well as vending machines.
Part Number
Manufacturer
Description
Unit Price
In Stock
Sunon
Manufacturer : Sunon Fans
Series : DP
Part Status : Active
Voltage - Rated : 220 ~ 240VAC
Size / Dimension : Square - 119mm L x 119mm H
Width : 25.50mm
Air Flow : 80.0 CFM (2.24m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 48.0 dB(A)
Power (Watts) : 19.00W
RPM : 2500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.65 lb (294.84g)
0
30 in stock
Sunon
Manufacturer : Sunon Fans
Series : DP
Part Status : Active
Voltage - Rated : 220 ~ 240VAC
Size / Dimension : Square - 119mm L x 119mm H
Width : 25.50mm
Air Flow : 80.0 CFM (2.24m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 48.0 dB(A)
Power (Watts) : 19.00W
RPM : 2500 RPM
Termination : 2 Terminals
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.65 lb (294.84g)
0
29 in stock
Sunon
Manufacturer : Sunon Fans
Series : DP
Part Status : Active
Voltage - Rated : 220 ~ 240VAC
Size / Dimension : Square - 119mm L x 119mm H
Width : 25.50mm
Air Flow : 78.0 CFM (2.18m鲁/min)
Static Pressure : 0.160 in H2O (39.8 Pa)
Bearing Type : Sleeve
Fan Type : Tubeaxial
Features : -
Noise : 46.0 dB(A)
Power (Watts) : 19.00W
RPM : 2300 RPM
Termination : 2 Terminals
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.65 lb (294.84g)
0
30 in stock
Sunon
Manufacturer : Sunon Fans
Series : DP
Part Status : Active
Voltage - Rated : 220 ~ 240VAC
Size / Dimension : Square - 119mm L x 119mm H
Width : 38.50mm
Air Flow : 84.0 CFM (2.35m鲁/min)
Static Pressure : 0.210 in H2O (52.3 Pa)
Bearing Type : Sleeve
Fan Type : Tubeaxial
Features : -
Noise : 38.0 dB(A)
Power (Watts) : 15.00W
RPM : 2500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, TUV, UL
Weight : 1.2 lbs (544.3g)
0
29 in stock
Sunon
Manufacturer : Sunon Fans
Series : DP
Part Status : Active
Voltage - Rated : 220 ~ 240VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 78.0 CFM (2.18m鲁/min)
Static Pressure : 0.130 in H2O (32.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 39.0 dB(A)
Power (Watts) : 10.00W
RPM : 2300 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 1.2 lbs (544.3g)
0
30 in stock
Sunon
Manufacturer : Sunon Fans
Series : DP
Part Status : Active
Voltage - Rated : 220 ~ 240VAC
Size / Dimension : Square - 119mm L x 119mm H
Width : 38.50mm
Air Flow : 63.0 CFM (1.76m鲁/min)
Static Pressure : 0.070 in H2O (17.4 Pa)
Bearing Type : Sleeve
Fan Type : Tubeaxial
Features : -
Noise : 32.0 dB(A)
Power (Watts) : 10.00W
RPM : 1800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 1.2 lbs (544.3g)
0
30 in stock
Sunon
Manufacturer : Sunon Fans
Series : EB
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 20.00mm
Air Flow : 8.9 CFM (0.249m鲁/min)
Static Pressure : 0.210 in H2O (52.3 Pa)
Bearing Type : Sleeve
Fan Type : Tubeaxial
Features : -
Noise : 25.5 dB(A)
Power (Watts) : 1.08W
RPM : 7200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : 0.068 lb (30.84g)
0
394 in stock
Sunon
Manufacturer : Sunon Fans
Series : EB
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 20.00mm
Air Flow : 7.7 CFM (0.216m鲁/min)
Static Pressure : 0.160 in H2O (39.8 Pa)
Bearing Type : Sleeve
Fan Type : Tubeaxial
Features : -
Noise : 21.0 dB(A)
Power (Watts) : 760mW
RPM : 6200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.069 lb (31.3g)
0
621 in stock
Sunon
Manufacturer : Sunon Fans
Series : EB
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 20.00mm
Air Flow : 7.7 CFM (0.216m鲁/min)
Static Pressure : 0.160 in H2O (39.8 Pa)
Bearing Type : Sleeve
Fan Type : Tubeaxial
Features : -
Noise : 21.0 dB(A)
Power (Watts) : 800mW
RPM : 6200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CUR, TUV, UL
Weight : 0.069 lb (31.3g)
0
100 in stock
Sunon
Manufacturer : Sunon Fans
Series : EB
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 25.00mm
Air Flow : 23.5 CFM (0.658m鲁/min)
Static Pressure : 0.210 in H2O (52.3 Pa)
Bearing Type : Sleeve
Fan Type : Tubeaxial
Features : -
Noise : 33.5 dB(A)
Power (Watts) : 1.62W
RPM : 4500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CUR, TUV, UL
Weight : 0.126 lb (57.15g)
0
215 in stock
Sunon
Manufacturer : Sunon Fans
Series : EB
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 25.00mm
Air Flow : 23.5 CFM (0.658m鲁/min)
Static Pressure : 0.210 in H2O (52.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 34.5 dB(A)
Power (Watts) : 1.90W
RPM : 4500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : -
Weight : 0.126 lb (57.15g)
0
1938 in stock
Sunon
Manufacturer : Sunon Fans
Series : EB
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 25.00mm
Air Flow : 23.5 CFM (0.658m鲁/min)
Static Pressure : 0.210 in H2O (52.3 Pa)
Bearing Type : Sleeve
Fan Type : Tubeaxial
Features : -
Noise : 33.5 dB(A)
Power (Watts) : 1.80W
RPM : 4500 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.126 lb (57.15g)
0
30 in stock
