Sunon
- Founded in 1980, Sunonwealth Electric Machine Industry Company Limited has always adhered to the business philosophy of “Brand, Innovation, and Value”. Step by step, it has now become a global leader in the fields of precision motors, mini fans, and thermal modules.
Sunon designs and manufactures a full range of high-performance fans, blowers and coolers. The company is committed to supplying the widest selection of quality axial fans and blowers, which includes DC brushless fans, micro DC blowers, CPU coolers, graphic card coolers and AC fans. Sunon manufactures some of the industries smallest, thinnest and most power efficient fans and blowers in sizes ranging from 0.315 inches (8mm) to 10 inches (250mm) in outside diameter and from 0.157 inches (4mm) to 1.5 inches (38mm) in thickness. More than 700 different models are available to customers.
Sunon’s fans, blowers and coolers find application in a wide range of industries and products. The company’s products are used in many of the world’s most popular personal computers, workstations, servers, networking hubs, scanners, printers and more. In office equipment, Sunon products can be found in copiers, fax machines and projectors. Sunon is equally at home in the appliance market, with applications for refrigerators, air cleaners and air heaters. Other markets include medical, laboratory and manufacturing equipment, as well as vending machines.
Part Number
Manufacturer
Description
Unit Price
In Stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 110/230VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 64.3 CFM (1.80m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 31.4 dB(A)
Power (Watts) : 1.80W
RPM : 2000 RPM
Termination : 2 Wire Leads
Ingress Protection : IP68 - Dust Tight, Waterproof
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.699 lb (317.06g)
0
50 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 100 ~ 240VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 64.3 CFM (1.80m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 31.4 dB(A)
Power (Watts) : 1.80W
RPM : 2000 RPM
Termination : 2 Wire Leads
Ingress Protection : IP68 - Dust Tight, Waterproof
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : ATEX, CE, CUR, TUV, UL
Weight : 0.699 lb (317.06g)
0
100 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 110/230VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 64.3 CFM (1.80m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 31.4 dB(A)
Power (Watts) : 1.80W
RPM : 2000 RPM
Termination : 2 Terminals
Ingress Protection : -
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.595 lb (269.89g)
0
37 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 110/230VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 64.3 CFM (1.80m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 31.4 dB(A)
Power (Watts) : 1.80W
RPM : 2000 RPM
Termination : 2 Terminals
Ingress Protection : IP21
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.595 lb (269.89g)
0
40 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 110/230VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 64.3 CFM (1.80m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 31.4 dB(A)
Power (Watts) : 1.80W
RPM : 2000 RPM
Termination : 2 Terminals
Ingress Protection : IP55 - Dust Protected, Water Resistant
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.699 lb (317.06g)
0
33 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 100 ~ 240VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 64.3 CFM (1.80m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 31.4 dB(A)
Power (Watts) : 1.80W
RPM : 2000 RPM
Termination : 2 Terminals
Ingress Protection : IP55 - Dust Protected, Water Resistant
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : ATEX, CE, CUR, TUV, UL
Weight : 0.699 lb (317.06g)
0
100 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 110/230VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 90.1 CFM (2.52m鲁/min)
Static Pressure : 0.310 in H2O (77.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 40.2 dB(A)
Power (Watts) : 3.40W
RPM : 3000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.595 lb (269.89g)
0
38 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 110/230VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 90.1 CFM (2.52m鲁/min)
Static Pressure : 0.310 in H2O (77.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 40.2 dB(A)
Power (Watts) : 3.40W
RPM : 3000 RPM
Termination : 2 Wire Leads
Ingress Protection : IP21
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.595 lb (269.89g)
0
40 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 110/230VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 90.1 CFM (2.52m鲁/min)
Static Pressure : 0.310 in H2O (77.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 40.2 dB(A)
Power (Watts) : 3.40W
RPM : 3000 RPM
Termination : 2 Wire Leads
Ingress Protection : IP55 - Dust Protected, Water Resistant
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.699 lb (317.06g)
0
39 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 100 ~ 240VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 90.1 CFM (2.52m鲁/min)
Static Pressure : 0.310 in H2O (77.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 40.2 dB(A)
Power (Watts) : 3.40W
RPM : 3000 RPM
Termination : 2 Wire Leads
Ingress Protection : IP55 - Dust Protected, Water Resistant
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : ATEX, CE, CUR, TUV, UL
Weight : 0.699 lb (317.06g)
0
100 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 110/230VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 90.1 CFM (2.52m鲁/min)
Static Pressure : 0.310 in H2O (77.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 40.2 dB(A)
Power (Watts) : 3.40W
RPM : 3000 RPM
Termination : 2 Wire Leads
Ingress Protection : IP68 - Dust Tight, Waterproof
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.699 lb (317.06g)
0
100 in stock
Sunon
Manufacturer : Sunon Fans
Series : CF
Part Status : Active
Voltage - Rated : 100 ~ 240VAC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 90.1 CFM (2.52m鲁/min)
Static Pressure : 0.310 in H2O (77.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Auto Restart, Electronic Commutation (EC), Dual Voltage
Noise : 40.2 dB(A)
Power (Watts) : 3.40W
RPM : 3000 RPM
Termination : 2 Wire Leads
Ingress Protection : IP68 - Dust Tight, Waterproof
Operating Temperature : -13 ~ 158°F (-25 ~ 70°C)
Approvals : ATEX, CE, CUR, TUV, UL
Weight : 0.699 lb (317.06g)
0
100 in stock
