Sunon
- Founded in 1980, Sunonwealth Electric Machine Industry Company Limited has always adhered to the business philosophy of “Brand, Innovation, and Value”. Step by step, it has now become a global leader in the fields of precision motors, mini fans, and thermal modules.
Sunon designs and manufactures a full range of high-performance fans, blowers and coolers. The company is committed to supplying the widest selection of quality axial fans and blowers, which includes DC brushless fans, micro DC blowers, CPU coolers, graphic card coolers and AC fans. Sunon manufactures some of the industries smallest, thinnest and most power efficient fans and blowers in sizes ranging from 0.315 inches (8mm) to 10 inches (250mm) in outside diameter and from 0.157 inches (4mm) to 1.5 inches (38mm) in thickness. More than 700 different models are available to customers.
Sunon’s fans, blowers and coolers find application in a wide range of industries and products. The company’s products are used in many of the world’s most popular personal computers, workstations, servers, networking hubs, scanners, printers and more. In office equipment, Sunon products can be found in copiers, fax machines and projectors. Sunon is equally at home in the appliance market, with applications for refrigerators, air cleaners and air heaters. Other markets include medical, laboratory and manufacturing equipment, as well as vending machines.
Part Number
Manufacturer
Description
Unit Price
In Stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 15.00mm
Air Flow : 13.0 CFM (0.364m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 29.0 dB(A)
Power (Watts) : 600mW
RPM : 5000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.073 lb (33.11g)
0
1164 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square/Rounded - 51.7mm L x 51.6mm H
Width : 15.00mm
Air Flow : 3.5 CFM (0.098m鲁/min)
Static Pressure : 0.400 in H2O (99.6 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Blower
Features : Auto Restart
Noise : 33.1 dB(A)
Power (Watts) : 680mW
RPM : 4000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.067 lb (30.39g)
0
819 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 15.00mm
Air Flow : 10.2 CFM (0.286m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 20.1 dB(A)
Power (Watts) : 420mW
RPM : 3800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.073 lb (33.11g)
0
145 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 15.00mm
Air Flow : 25.2 CFM (0.706m鲁/min)
Static Pressure : 0.310 in H2O (77.2 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 38.1 dB(A)
Power (Watts) : 1.38W
RPM : 7200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.073 lb (33.11g)
0
606 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 50mm L x 50mm H
Width : 15.00mm
Air Flow : 18.6 CFM (0.521m鲁/min)
Static Pressure : 0.310 in H2O (77.2 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart, Locked Rotor Sensor
Noise : 38.1 dB(A)
Power (Watts) : 1.32W
RPM : 7200 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.073 lb (33.11g)
0
140 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square/Rounded - 51.7mm L x 51.6mm H
Width : 15.00mm
Air Flow : 5.4 CFM (0.151m鲁/min)
Static Pressure : 0.970 in H2O (241.6 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Blower
Features : Auto Restart
Noise : 42.2 dB(A)
Power (Watts) : 2.04W
RPM : 6000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 122°F (-10 ~ 50°C)
Approvals : CE, CUR, TUV, UL
Weight : 0.066 lb (29.94g)
0
1290 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 10.00mm
Air Flow : 16.3 CFM (0.456m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart, Locked Rotor Sensor
Noise : 28.5 dB(A)
Power (Watts) : 1.30W
RPM : 4000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.051 lb (23.13g)
0
150 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 10.00mm
Air Flow : 16.3 CFM (0.456m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart, Speed Sensor (Tach)
Noise : 28.5 dB(A)
Power (Watts) : 1.30W
RPM : 4000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.051 lb (23.13g)
0
273 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square/Rounded - 60mm L x 60mm H
Width : 15.00mm
Air Flow : 5.7 CFM (0.160m鲁/min)
Static Pressure : 0.440 in H2O (109.6 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Blower
Features : Auto Restart
Noise : 40.3 dB(A)
Power (Watts) : 1.08W
RPM : 5000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.079 lb (35.83g)
0
1766 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.00mm
Air Flow : 17.6 CFM (0.493m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 21.3 dB(A)
Power (Watts) : 580mW
RPM : 3000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.077 lb (34.93g)
0
100 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.00mm
Air Flow : 30.4 CFM (0.851m鲁/min)
Static Pressure : 0.220 in H2O (54.8 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart
Noise : 36.2 dB(A)
Power (Watts) : 2.22W
RPM : 5400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.077 lb (34.93g)
0
3435 in stock
Sunon
Manufacturer : Sunon Fans
Series : MagLev® MF
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.00mm
Air Flow : 30.4 CFM (0.851m鲁/min)
Static Pressure : 0.220 in H2O (54.8 Pa)
Bearing Type : Vapo-Bearing™
Fan Type : Tubeaxial
Features : Auto Restart, Speed Sensor (Tach)
Noise : 36.2 dB(A)
Power (Watts) : 2.22W
RPM : 5400 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, CUR, TUV, UL
Weight : 0.078 lb (35.38g)
0
238 in stock
