Seoul Semiconductor
- Seoul Semiconductor manufacturers and packages a wide selection of light emitting diodes (LEDs) for the automotive, lighting, appliance, mobile, signage, and back lighting units (BLU) markets. The company is the world’s fifth largest LED supplier, holding more than 10, 000 patents globally, while offering a wide range of LED technology and production capacity in areas such as "nPola", deep UV LEDs, and "Acrich", the world’s first commercially produced AC LED.
Part Number
Manufacturer
Description
Unit Price
In Stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3500K (3200K ~ 3700K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 124 lm (107 lm ~ 140 lm)
Current - Test : 40mA
Voltage - Forward (Vf) (Typ) : 32.5V
Lumens/Watt @ Current - Test : 95 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 45mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1411 (3528 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.110" W (3.50mm x 2.80mm)
Height - Seated (Max) : 0.028" (0.70mm)
0
1725 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Active
Color : White, Cool
CCT (K) : 5600K (5300K ~ 6000K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 128 lm, 136 lm
Current - Test : 40mA
Voltage - Forward (Vf) (Typ) : 32.5V
Lumens/Watt @ Current - Test : 98 lm/W, 105 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 45mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1411 (3528 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.110" W (3.50mm x 2.80mm)
Height - Seated (Max) : 0.028" (0.70mm)
0
457 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich MJT 2525
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3450K (3200K ~ 3700K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 90 lm (85 lm ~ 95 lm)
Current - Test : 40mA
Voltage - Forward (Vf) (Typ) : 23V
Lumens/Watt @ Current - Test : 98 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 60mA
Viewing Angle : 130°
Mounting Type : Surface Mount
Package / Case : 1010 (2525 Metric)
Supplier Device Package : 2525
Size / Dimension : 0.101" L x 0.101" W (2.57mm x 2.57mm)
Height - Seated (Max) : 0.053" (1.34mm)
0
2271 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich MJT 2525
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3050K (2900K ~ 3200K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 90 lm (85 lm ~ 95 lm)
Current - Test : 40mA
Voltage - Forward (Vf) (Typ) : 23V
Lumens/Watt @ Current - Test : 98 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 60mA
Viewing Angle : 130°
Mounting Type : Surface Mount
Package / Case : 1010 (2525 Metric)
Supplier Device Package : 2525
Size / Dimension : 0.101" L x 0.101" W (2.57mm x 2.57mm)
Height - Seated (Max) : 0.053" (1.34mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich MJT 2525
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 2750K (2600K ~ 2900K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 90 lm (85 lm ~ 95 lm)
Current - Test : 40mA
Voltage - Forward (Vf) (Typ) : 23V
Lumens/Watt @ Current - Test : 98 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 60mA
Viewing Angle : 130°
Mounting Type : Surface Mount
Package / Case : 1010 (2525 Metric)
Supplier Device Package : 2525
Size / Dimension : 0.101" L x 0.101" W (2.57mm x 2.57mm)
Height - Seated (Max) : 0.053" (1.34mm)
0
2707 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC6 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5600K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 870 lm (Typ)
Current - Test : 180mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 131 lm/W
Current - Max : 320mA
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 13.50mm L x 13.50mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
281 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC6 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 870 lm (Typ)
Current - Test : 180mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 131 lm/W
Current - Max : 320mA
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 13.50mm L x 13.50mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
265 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC12 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5600K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 1780 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 137 lm/W
Current - Max : 480mA
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 19.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
248 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC18 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5600K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 2520 lm (Typ)
Current - Test : 500mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 136 lm/W
Current - Max : 640mA
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 19.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
1 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC18 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 2520 lm (Typ)
Current - Test : 500mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 136 lm/W
Current - Max : 640mA
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 19.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
81 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC25 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5600K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 3650 lm (Typ)
Current - Test : 700mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 141 lm/W
Current - Max : 960mA
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
210 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : ZC25 Z-Power COB
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 3650 lm (Typ)
Current - Test : 700mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 141 lm/W
Current - Max : 960mA
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 2.30mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
17 in stock
