- Seoul Semiconductor manufacturers and packages a wide selection of light emitting diodes (LEDs) for the automotive, lighting, appliance, mobile, signage, and back lighting units (BLU) markets. The company is the world’s fifth largest LED supplier, holding more than 10, 000 patents globally, while offering a wide range of LED technology and production capacity in areas such as "nPola", deep UV LEDs, and "Acrich", the world’s first commercially produced AC LED.
Part Number
Manufacturer
Description
Unit Price
In Stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Z Power, P4
Part Status : Obsolete
Type : LED Module
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 66 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 58 lm/W
Current - Max : 800mA
CRI (Color Rendering Index) : 93 (Typ)
Viewing Angle : 124°
Features : -
Size / Dimension : 19.90mm Diameter
Height : 6.78mm
Light Emitting Surface (LES) : 5.60mm Diameter
Lens Type : Domed
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z Power
Part Status : Active
Color : Red
Wavelength : 625nm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.3V
Lumens/Watt @ Current - Test : 60 lm/W
Current - Max : 800mA
Flux @ Current/Temperature - Test : 48 lm (Typ)
Temperature - Test : 25°C
Viewing Angle : 130°
Mounting Type : Surface Mount
Package / Case : 2-SMD, Gull Wing Exposed Pad
Supplier Device Package : SMD
Size / Dimension : 0.315" Dia (8.00mm)
Height - Seated (Max) : 0.208" (5.28mm)
0
337 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Z Power P3-II
Part Status : Obsolete
Color : Red
Wavelength : 622nm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.5V
Lumens/Watt @ Current - Test : 43 lm/W
Current - Max : 400mA
Flux @ Current/Temperature - Test : 38 lm (Typ)
Temperature - Test : 25°C
Viewing Angle : 130°
Mounting Type : Surface Mount
Package / Case : 2-SMD, Gull Wing Exposed Pad
Supplier Device Package : SMD
Size / Dimension : 0.315" Dia (8.00mm)
Height - Seated (Max) : 0.208" (5.28mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Z Power, P4
Part Status : Obsolete
Color : White, Neutral
CCT (K) : 4000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 86 lm (80 lm ~ 91 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.1V
Lumens/Watt @ Current - Test : 79 lm/W
CRI (Color Rendering Index) : 93 (Typ)
Current - Max : 800mA
Viewing Angle : 124°
Mounting Type : Surface Mount
Package / Case : 2-SMD, Gull Wing Exposed Pad
Supplier Device Package : -
Size / Dimension : 0.315" Dia (8.00mm)
Height - Seated (Max) : 0.208" (5.28mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Z Power, P4
Part Status : Obsolete
Color : White, Neutral
CCT (K) : 4000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 86 lm (80 lm ~ 91 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.1V
Lumens/Watt @ Current - Test : 79 lm/W
CRI (Color Rendering Index) : 93 (Typ)
Current - Max : 800mA
Viewing Angle : 126°
Mounting Type : Surface Mount
Package / Case : 2-SMD, Gull Wing Exposed Pad
Supplier Device Package : -
Size / Dimension : 0.315" Dia (8.00mm)
Height - Seated (Max) : 0.208" (5.28mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Z Power, P4
Part Status : Obsolete
Color : White, Neutral
CCT (K) : 4000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 65 lm (60 lm ~ 70 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 57 lm/W
CRI (Color Rendering Index) : 93 (Typ)
Current - Max : 800mA
Viewing Angle : 124°
Mounting Type : Surface Mount
Package / Case : 2-SMD, Gull Wing Exposed Pad
Supplier Device Package : -
Size / Dimension : 0.315" Dia (8.00mm)
Height - Seated (Max) : 0.208" (5.28mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Z Power, P4
Part Status : Obsolete
Color : White, Neutral
CCT (K) : 4000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 75 lm (70 lm ~ 80 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 66 lm/W
CRI (Color Rendering Index) : 93 (Typ)
Current - Max : 800mA
Viewing Angle : 124°
Mounting Type : Surface Mount
Package / Case : 2-SMD, Gull Wing Exposed Pad
Supplier Device Package : -
Size / Dimension : 0.315" Dia (8.00mm)
Height - Seated (Max) : 0.208" (5.28mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Z Power, P4
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 61 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 54 lm/W
Current - Max : 350mA
CRI (Color Rendering Index) : 93 (Typ)
Viewing Angle : 124°
Features : -
Size / Dimension : 19.90mm L x 19.90mm W
Height : 6.78mm
Light Emitting Surface (LES) : 6.00mm Diameter
Lens Type : Domed
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Series : Acrich
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 5600K (5300K ~ 6000K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 165 lm (Typ)
Current - Test : 20mA
Voltage - Forward (Vf) (Typ) : 64V
Lumens/Watt @ Current - Test : 129 lm/W
CRI (Color Rendering Index) : 69
Current - Max : 40mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1616 (4040 Metric)
Supplier Device Package : 4040
Size / Dimension : 0.157" L x 0.157" W (4.00mm x 4.00mm)
Height - Seated (Max) : 0.094" (2.40mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Series : Acrich MJT 4040
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 5000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 170 lm (140 lm ~ 200 lm)
Current - Test : 20mA
Voltage - Forward (Vf) (Typ) : 64V
Lumens/Watt @ Current - Test : 133 lm/W
CRI (Color Rendering Index) : 69
Current - Max : 40mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1616 (4040 Metric)
Supplier Device Package : 4040
Size / Dimension : 0.157" L x 0.157" W (4.00mm x 4.00mm)
Height - Seated (Max) : 0.094" (2.40mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich MJT 4040
Part Status : Discontinued at
Color : White, Neutral
CCT (K) : 4500K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 170 lm (140 lm ~ 200 lm)
Current - Test : 20mA
Voltage - Forward (Vf) (Typ) : 64V
Lumens/Watt @ Current - Test : 133 lm/W
CRI (Color Rendering Index) : 69
Current - Max : 40mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1616 (4040 Metric)
Supplier Device Package : 4040
Size / Dimension : 0.157" L x 0.157" W (4.00mm x 4.00mm)
Height - Seated (Max) : 0.094" (2.40mm)
0
21 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich MJT 5050
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 166 lm, 189 lm
Current - Test : 20mA
Voltage - Forward (Vf) (Typ) : 63V
Lumens/Watt @ Current - Test : 132 lm/W, 150 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 60mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 2020 (5050 Metric)
Supplier Device Package : 5050
Size / Dimension : 0.197" L x 0.197" W (5.00mm x 5.00mm)
Height - Seated (Max) : 0.030" (0.75mm)
0
755 in stock
