Seoul Semiconductor
- Seoul Semiconductor manufacturers and packages a wide selection of light emitting diodes (LEDs) for the automotive, lighting, appliance, mobile, signage, and back lighting units (BLU) markets. The company is the world’s fifth largest LED supplier, holding more than 10, 000 patents globally, while offering a wide range of LED technology and production capacity in areas such as "nPola", deep UV LEDs, and "Acrich", the world’s first commercially produced AC LED.
Part Number
Manufacturer
Description
Unit Price
In Stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Acrich A4
Part Status : Obsolete
Color : White, Warm
CCT (K) : 3000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 50 lm (Typ)
Current - Test : 20mA
Voltage - Forward (Vf) (Typ) : 55VAC
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : 85 (Typ)
Current - Max : -
Viewing Angle : 134°
Mounting Type : Surface Mount
Package / Case : 2828 (7070 Metric)
Supplier Device Package : -
Size / Dimension : 0.276" L x 0.276" W (7.00mm x 7.00mm)
Height - Seated (Max) : 0.124" (3.15mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Acrich
Part Status : Obsolete
Color : White, Cool
CCT (K) : 6300K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 80 lm (Typ)
Current - Test : 20mA
Voltage - Forward (Vf) (Typ) : 100/110VAC
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : 70 (Typ)
Current - Max : -
Viewing Angle : 110°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Gull Wing
Supplier Device Package : -
Size / Dimension : 0.315" Dia (8.00mm)
Height - Seated (Max) : 0.226" (5.75mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Acriche A2
Part Status : Obsolete
Type : LED Engine
Color : White, Cool
CCT (K) : 6300K
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 80 lm (Typ)
Current - Test : 20mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : 20mA
CRI (Color Rendering Index) : 70 (Typ)
Viewing Angle : 110°
Features : -
Size / Dimension : 25.00mm L x 25.00mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 6300K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 330 lm (Typ)
Current - Test : 40mA
Voltage - Forward (Vf) (Typ) : 100/110/120VAC
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : 65
Current - Max : -
Viewing Angle : 130°
Mounting Type : Surface Mount
Package / Case : 2-SMD, Gull Wing
Supplier Device Package : -
Size / Dimension : 0.472" Dia (12.00mm)
Height - Seated (Max) : 0.265" (6.74mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 5600K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 330 lm (Typ)
Current - Test : 40mA
Voltage - Forward (Vf) (Typ) : 100/110/120VAC
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : 65 (Typ)
Current - Max : -
Viewing Angle : 130°
Mounting Type : Surface Mount
Package / Case : 2-SMD, Gull Wing
Supplier Device Package : -
Size / Dimension : 0.472" Dia (12.00mm)
Height - Seated (Max) : 0.265" (6.74mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Acriche A2
Part Status : Obsolete
Type : LED Engine
Color : White, Cool
CCT (K) : 6300K
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 215 lm (Typ)
Current - Test : 40mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : 40mA
CRI (Color Rendering Index) : 65 (Typ)
Viewing Angle : 130°
Features : -
Size / Dimension : 30.00mm L x 30.00mm W
Height : 8.14mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z Power
Part Status : Active
Color : Blue
Wavelength : 465nm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.25V
Lumens/Watt @ Current - Test : 19 lm/W
Current - Max : 1A
Flux @ Current/Temperature - Test : 22 lm (Typ)
Temperature - Test : 25°C
Viewing Angle : 130°
Mounting Type : Surface Mount
Package / Case : 2-SMD, Gull Wing
Supplier Device Package : -
Size / Dimension : 0.315" Dia (8.00mm)
Height - Seated (Max) : 0.208" (5.28mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Z Power P3-II
Part Status : Obsolete
Color : Blue
Wavelength : 460nm (455nm ~ 465nm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.5V
Lumens/Watt @ Current - Test : 12 lm/W
Current - Max : 500mA
Flux @ Current/Temperature - Test : 15 lm (Typ)
Temperature - Test : 25°C
Viewing Angle : 130°
Mounting Type : Surface Mount
Package / Case : 2-SMD, Gull Wing
Supplier Device Package : -
Size / Dimension : 0.315" Dia (8.00mm)
Height - Seated (Max) : 0.208" (5.28mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Color : White, Neutral
Configuration : Standard
Lens Color : -
Lens Transparency : -
Millicandela Rating : 5000mcd
Lens Style : Round with Flat Top
Lens Size : 4.00mm Dia
Voltage - Forward (Vf) (Typ) : 3.3V
Current - Test : 3 x 20mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Wavelength - Dominant : 4800K
Wavelength - Peak : -
Features : -
Package / Case : 6-SMD, J-Lead
Supplier Device Package : SMD
Size / Dimension : 5.00mm L x 5.00mm W
Height (Max) : 1.40mm
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Color : White, Neutral
Configuration : Standard
Lens Color : -
Lens Transparency : -
Millicandela Rating : 4500mcd
Lens Style : Round with Flat Top
Lens Size : 4.00mm Dia
Voltage - Forward (Vf) (Typ) : 3.3V
Current - Test : 3 x 20mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Wavelength - Dominant : 4800K
Wavelength - Peak : -
Features : -
Package / Case : 6-SMD, J-Lead
Supplier Device Package : SMD
Size / Dimension : 5.00mm L x 5.00mm W
Height (Max) : 1.40mm
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Discontinued at
Type : AC DC Offline Switcher
Topology : -
Internal Switch(s) : Yes
Number of Outputs : 4
Voltage - Supply (Min) : 120VAC
Voltage - Supply (Max) : 230VAC
Voltage - Output : -
Current - Output / Channel : -
Frequency : -
Dimming : Analog, TRIAC
Applications : -
Operating Temperature : -30°C ~ 100°C (TA)
Mounting Type : Surface Mount
Package / Case : 12-VQFN Exposed Pad
Supplier Device Package : -
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z Power P5-II
Part Status : Active
Color : Red, Green, Blue (RGB)
Wavelength : 625nm Red, 525nm Green, 460nm Blue
Current - Test : 350mA Red, 350mA Green, 350mA Blue
Voltage - Forward (Vf) (Typ) : 2.5V Red, 3.8V Green, 3.6V Blue
Lumens/Watt @ Current - Test : 40 lm/W Red, 43 lm/W Green, 10 lm/W Blue
Current - Max : 400mA Red, 400mA Green, 400mA Blue
Flux @ Current/Temperature - Test : 35 lm Red, 57 lm Green, 13 lm Blue
Temperature - Test : 25°C
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 2420 (6050 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.236" L x 0.197" W (6.00mm x 5.00mm)
Height - Seated (Max) : 0.047" (1.20mm)
0
100 in stock
