IXYS Corporation
- IXYS Corporation/Littelfuse has gained a worldwide reputation as a premier power semiconductor manufacturer. Its diversified product base of specialized power semiconductors, integrated circuits and RF power include low on-resistance Power MOSFETs, Ultra Fast switching IGBTs, Fast Recovery Diodes (FREDs), SCR and Diode Modules, Rectifier Bridges, and Power Interface ICs for applications ranging across industrial, transportation, telecommunications, computer, medical, consumer and clean tech markets.
With the acquisition of IXYS, Littelfuse significantly expands the breadth of its power semiconductor portfolio, with solutions spanning a full range of technologies. This diverse portfolio will provide customers with the best technology and enhanced, differentiated capabilities in target markets and geographies as well as deliver greater industry access and increased growth opportunities.
Part Number
Manufacturer
Description
Unit Price
In Stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Bulk
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Voltage - Collector Emitter Breakdown (Max) : 1700V
Current - Collector (Ic) (Max) : 16A
Current - Collector Pulsed (Icm) : 40A
Vce(on) (Max) @ Vge, Ic : 6V @ 15V, 10A
Power - Max : 150W
Switching Energy : 1.2mJ (off)
Input Type : Standard
Gate Charge : 65nC
Td (on/off) @ 25°C : 15ns/160ns
Test Condition : 1360V, 10A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 360ns
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247AD (IXBH)
0
42 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Voltage - Collector Emitter Breakdown (Max) : 3000V
Current - Collector (Ic) (Max) : 50A
Current - Collector Pulsed (Icm) : 140A
Vce(on) (Max) @ Vge, Ic : 3.2V @ 15V, 20A
Power - Max : 250W
Switching Energy : -
Input Type : Standard
Gate Charge : 105nC
Td (on/off) @ 25°C : -
Test Condition : -
Reverse Recovery Time (trr) : 1.35µs
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247AD (IXBH)
0
86 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Voltage - Collector Emitter Breakdown (Max) : 3600V
Current - Collector (Ic) (Max) : 70A
Current - Collector Pulsed (Icm) : 220A
Vce(on) (Max) @ Vge, Ic : 3.4V @ 15V, 20A
Power - Max : 430W
Switching Energy : 15.5mJ (on), 4.3mJ (off)
Input Type : Standard
Gate Charge : 110nC
Td (on/off) @ 25°C : 18ns/238ns
Test Condition : 1500V, 20A, 10 Ohm, 15V
Reverse Recovery Time (trr) : 1.7µs
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3 Variant
Supplier Device Package : TO-247HV
0
436 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Voltage - Collector Emitter Breakdown (Max) : 2500V
Current - Collector (Ic) (Max) : 5A
Current - Collector Pulsed (Icm) : 13A
Vce(on) (Max) @ Vge, Ic : 3.5V @ 15V, 2A
Power - Max : 32W
Switching Energy : -
Input Type : Standard
Gate Charge : 10.6nC
Td (on/off) @ 25°C : -
Test Condition : -
Reverse Recovery Time (trr) : 920ns
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247AD (IXBH)
0
109 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Voltage - Collector Emitter Breakdown (Max) : 3000V
Current - Collector (Ic) (Max) : 80A
Current - Collector Pulsed (Icm) : 280A
Vce(on) (Max) @ Vge, Ic : 3.2V @ 15V, 32A
Power - Max : 400W
Switching Energy : -
Input Type : Standard
Gate Charge : 142nC
Td (on/off) @ 25°C : -
Test Condition : -
Reverse Recovery Time (trr) : 1.5µs
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247AD (IXBH)
0
299 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Bulk
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Voltage - Collector Emitter Breakdown (Max) : 1600V
Current - Collector (Ic) (Max) : 33A
Current - Collector Pulsed (Icm) : 40A
Vce(on) (Max) @ Vge, Ic : 7.1V @ 15V, 20A
Power - Max : 350W
Switching Energy : -
Input Type : Standard
Gate Charge : 130nC
Td (on/off) @ 25°C : -
Test Condition : 960V, 20A, 22 Ohm, 15V
Reverse Recovery Time (trr) : -
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247AD (IXBH)
0
36 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Bulk
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Voltage - Collector Emitter Breakdown (Max) : 1700V
Current - Collector (Ic) (Max) : 80A
Current - Collector Pulsed (Icm) : 300A
Vce(on) (Max) @ Vge, Ic : 2.8V @ 15V, 42A
Power - Max : 360W
Switching Energy : -
Input Type : Standard
Gate Charge : 188nC
Td (on/off) @ 25°C : -
Test Condition : -
Reverse Recovery Time (trr) : 1.32µs
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-247-3
Supplier Device Package : TO-247AD (IXBH)
0
502 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Voltage - Collector Emitter Breakdown (Max) : 3000V
Current - Collector (Ic) (Max) : 130A
Current - Collector Pulsed (Icm) : 600A
Vce(on) (Max) @ Vge, Ic : 3.2V @ 15V, 55A
Power - Max : 625W
Switching Energy : -
Input Type : Standard
Gate Charge : 335nC
Td (on/off) @ 25°C : -
Test Condition : -
Reverse Recovery Time (trr) : 1.9µs
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-264-3, TO-264AA
Supplier Device Package : TO-264
0
100 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Voltage - Collector Emitter Breakdown (Max) : 1700V
Current - Collector (Ic) (Max) : 200A
Current - Collector Pulsed (Icm) : 580A
Vce(on) (Max) @ Vge, Ic : 3.1V @ 15V, 75A
Power - Max : 1040W
Switching Energy : -
Input Type : Standard
Gate Charge : 350nC
Td (on/off) @ 25°C : -
Test Condition : -
Reverse Recovery Time (trr) : 1.5µs
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : TO-264-3, TO-264AA
Supplier Device Package : TO-264
0
49 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Packaging : Tube
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Voltage - Collector Emitter Breakdown (Max) : 3600V
Current - Collector (Ic) (Max) : 92A
Current - Collector Pulsed (Icm) : 720A
Vce(on) (Max) @ Vge, Ic : 3.4V @ 15V, 60A
Power - Max : 417W
Switching Energy : -
Input Type : Standard
Gate Charge : 450nC
Td (on/off) @ 25°C : 50ns/340ns
Test Condition : 960V, 60A, 4.7 Ohm, 15V
Reverse Recovery Time (trr) : 1.95µs
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : ISOPLUSi5-Pak™
Supplier Device Package : ISOPLUSi5-Pak™
0
65 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Configuration : Single
Voltage - Collector Emitter Breakdown (Max) : 1700V
Current - Collector (Ic) (Max) : 42A
Power - Max : 312W
Vce(on) (Max) @ Vge, Ic : 6V @ 15V, 21A
Current - Collector Cutoff (Max) : 50µA
Input Capacitance (Cies) @ Vce : 3.5nF @ 25V
Input : Standard
NTC Thermistor : No
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Chassis Mount
Package / Case : SOT-227-4, miniBLOC
Supplier Device Package : SOT-227B
0
100 in stock
IXYS Corporation / Littelfuse
Manufacturer : IXYS
Series : BIMOSFET™
Part Status : Active
IGBT Type : -
Configuration : Single
Voltage - Collector Emitter Breakdown (Max) : 1700V
Current - Collector (Ic) (Max) : 145A
Power - Max : 625W
Vce(on) (Max) @ Vge, Ic : 3.1V @ 15V, 75A
Current - Collector Cutoff (Max) : 25µA
Input Capacitance (Cies) @ Vce : 6.93nF @ 25V
Input : Standard
NTC Thermistor : No
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Chassis Mount
Package / Case : SOT-227-4, miniBLOC
Supplier Device Package : SOT-227B
0
100 in stock
