Vishay
- Vishay’s product portfolio is an unmatched collection of discrete semiconductors (diodes, MOSFETs, and optoelectronics) and passive components (resistors, inductors, and capacitors). These components are used in virtually all types of electronic devices and equipment in the industrial, computing, automotive, consumer, telecommunications, military, aerospace, and medical markets. Vishay is proud to be a major partner with Digi-Key.
Part Number
Manufacturer
Description
Unit Price
In Stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Mounting Type : Surface Mount
Circuit : SPST-NO (1 Form A)
Output Type : AC, DC
Voltage - Input : 1.1VDC
Voltage - Load : 0V ~ 60V
Load Current : 100mA
On-State Resistance (Max) : 5 Ohms
Termination Style : Gull Wing
Package / Case : 4-SOP (0.173", 4.40mm)
Supplier Device Package : 4-SOP
0
10869 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Mounting Type : Surface Mount
Circuit : SPST-NO (1 Form A)
Output Type : AC, DC
Voltage - Input : 1.3VDC
Voltage - Load : 0V ~ 60V
Load Current : 2A
On-State Resistance (Max) : 250 mOhms
Termination Style : Gull Wing
Package / Case : 6-SMD (0.300", 7.62mm)
Supplier Device Package : 6-SMD
0
100 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Mounting Type : Through Hole
Circuit : SPST-NO (1 Form A)
Output Type : AC, DC
Voltage - Input : 1.3VDC
Voltage - Load : 0V ~ 60V
Load Current : 2A
On-State Resistance (Max) : 250 mOhms
Termination Style : PC Pin
Package / Case : 6-DIP (0.300", 7.62mm)
Supplier Device Package : 6-DIP
0
100 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 4000Vrms
Current Transfer Ratio (Min) : 40% @ 10mA
Current Transfer Ratio (Max) : 80% @ 10mA
Turn On / Turn Off Time (Typ) : 3µs, 3µs
Rise / Fall Time (Typ) : 3µs, 2µs
Input Type : DC
Output Type : Transistor with Base
Voltage - Output (Max) : 70V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.3V
Current - DC Forward (If) (Max) : 60mA
Vce Saturation (Max) : 400mV
Operating Temperature : -40°C ~ 100°C
Mounting Type : Surface Mount
Package / Case : 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package : 8-SOIC
0
2000 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 4000Vrms
Current Transfer Ratio (Min) : 100% @ 10mA
Current Transfer Ratio (Max) : 200% @ 10mA
Turn On / Turn Off Time (Typ) : 3µs, 3µs
Rise / Fall Time (Typ) : 3µs, 2µs
Input Type : DC
Output Type : Transistor with Base
Voltage - Output (Max) : 70V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.3V
Current - DC Forward (If) (Max) : 60mA
Vce Saturation (Max) : 400mV
Operating Temperature : -40°C ~ 100°C
Mounting Type : Surface Mount
Package / Case : 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package : 8-SOIC
0
4627 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac, Power
Zero Crossing Circuit : No
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 210V/µs (Typ)
Current - LED Trigger (Ift) (Max) : 10mA
Current - On State (It (RMS)) (Max) : 900mA
Current - Hold (Ih) : 25mA
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.3V (Max)
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm), 7 Leads
Supplier Device Package : 8-DIP
Approvals : cUR, UR
0
1971 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac, Power
Zero Crossing Circuit : No
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 210V/µs (Typ)
Current - LED Trigger (Ift) (Max) : 10mA
Current - On State (It (RMS)) (Max) : 1A
Current - Hold (Ih) : 25mA
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.4V (Max)
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm), 7 Leads
Supplier Device Package : 8-DIP
Approvals : cUR, UR
0
15559 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac, Power
Zero Crossing Circuit : No
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 210V/µs (Typ)
Current - LED Trigger (Ift) (Max) : 10mA
Current - On State (It (RMS)) (Max) : 1A
Current - Hold (Ih) : 25mA
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.4V (Max)
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm), 7 Leads
Supplier Device Package : 8-DIP
Approvals : cUR, UR, VDE
0
2000 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Output Type : Triac, Power
Zero Crossing Circuit : No
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 210V/µs (Typ)
Current - LED Trigger (Ift) (Max) : 10mA
Current - On State (It (RMS)) (Max) : 1A
Current - Hold (Ih) : 25mA
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.4V (Max)
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 8-SMD (7 Leads), Gull Wing
Supplier Device Package : 8-SMD
Approvals : cUR, UR
0
542 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : -
Series : -
Part Status : Active
Output Type : Triac, Power
Zero Crossing Circuit : No
Number of Channels : 1
Voltage - Isolation : 4470Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 600V/µs (Typ)
Current - LED Trigger (Ift) (Max) : 10mA
Current - On State (It (RMS)) (Max) : 1A
Current - Hold (Ih) : 25mA
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.4V (Max)
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm), 7 Leads
Supplier Device Package : 8-DIP
Approvals : cUR, UR, VDE
0
1885 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Output Type : Triac, Power
Zero Crossing Circuit : No
Number of Channels : 1
Voltage - Isolation : 4470Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 600V/µs (Typ)
Current - LED Trigger (Ift) (Max) : 10mA
Current - On State (It (RMS)) (Max) : 1A
Current - Hold (Ih) : 25mA
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.4V (Max)
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 8-SMD (7 Leads), Gull Wing
Supplier Device Package : 8-SMD
Approvals : cUR, UR, VDE
0
975 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac, Power
Zero Crossing Circuit : No
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 210V/µs (Typ)
Current - LED Trigger (Ift) (Max) : 10mA
Current - On State (It (RMS)) (Max) : 900mA
Current - Hold (Ih) : 25mA
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.3V (Max)
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm), 7 Leads
Supplier Device Package : 8-DIP
Approvals : cUR, UR, VDE
0
2000 in stock
