Vishay
- Vishay’s product portfolio is an unmatched collection of discrete semiconductors (diodes, MOSFETs, and optoelectronics) and passive components (resistors, inductors, and capacitors). These components are used in virtually all types of electronic devices and equipment in the industrial, computing, automotive, consumer, telecommunications, military, aerospace, and medical markets. Vishay is proud to be a major partner with Digi-Key.
Part Number
Manufacturer
Description
Unit Price
In Stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 8200Vrms
Current Transfer Ratio (Min) : 50% @ 5mA
Current Transfer Ratio (Max) : 300% @ 5mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.7µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.32V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 4-SMD, Gull Wing
Supplier Device Package : 4-SMD
0
100 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 13900VDC
Current Transfer Ratio (Min) : 50% @ 10mA
Current Transfer Ratio (Max) : 300% @ 10mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.7µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.25V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 4-EDIP (0.300", 7.62mm)
Supplier Device Package : 4-DIP
0
2388 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 13900VDC
Current Transfer Ratio (Min) : 63% @ 10mA
Current Transfer Ratio (Max) : 125% @ 10mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.7µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.25V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 4-EDIP (0.300", 7.62mm)
Supplier Device Package : 4-DIP
0
792 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 13900VDC
Current Transfer Ratio (Min) : 80% @ 5mA
Current Transfer Ratio (Max) : 240% @ 5mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.7µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.32V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 4-SMD, Gull Wing
Supplier Device Package : 4-SMD
0
1279 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 13900VDC
Current Transfer Ratio (Min) : 100% @ 5mA
Current Transfer Ratio (Max) : 300% @ 5mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.7µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.32V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 4-SMD, Gull Wing
Supplier Device Package : 4-SMD
0
3928 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 13900VDC
Current Transfer Ratio (Min) : 50% @ 5mA
Current Transfer Ratio (Max) : 150% @ 5mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.7µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.32V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 4-SMD, Gull Wing
Supplier Device Package : 4-SMD
0
35 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 13900VDC
Current Transfer Ratio (Min) : 100% @ 10mA
Current Transfer Ratio (Max) : 200% @ 10mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.7µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.25V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 4-EDIP (0.300", 7.62mm)
Supplier Device Package : 4-DIP
0
5752 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 11600VDC
Current Transfer Ratio (Min) : 50% @ 5mA
Current Transfer Ratio (Max) : 300% @ 5mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.4µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.25V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 4-DIP (0.300", 7.62mm)
Supplier Device Package : 4-DIP
0
1458 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 13900VDC
Current Transfer Ratio (Min) : 50% @ 5mA
Current Transfer Ratio (Max) : 300% @ 5mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.7µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.32V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 4-SMD, Gull Wing
Supplier Device Package : 4-SMD
0
2800 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 13900VDC
Current Transfer Ratio (Min) : 50% @ 10mA
Current Transfer Ratio (Max) : 300% @ 10mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.7µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.25V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 4-DIP (0.300", 7.62mm)
Supplier Device Package : 4-DIP
0
1458 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 13900VDC
Current Transfer Ratio (Min) : 100% @ 10mA
Current Transfer Ratio (Max) : 200% @ 10mA
Turn On / Turn Off Time (Typ) : 5µs, 3µs
Rise / Fall Time (Typ) : 2.4µs, 2.7µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 32V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.25V
Current - DC Forward (If) (Max) : 75mA
Vce Saturation (Max) : 300mV
Operating Temperature : -55°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 4-DIP (0.300", 7.62mm)
Supplier Device Package : 4-DIP
0
876 in stock
Vishay / Semiconductor - Opto Division
Manufacturer : Vishay Semiconductor Opto Division
Packaging : Tube
Series : -
Part Status : Active
Sensing Distance : 0.197" (5mm)
Sensing Method : Reflective
Voltage - Collector Emitter Breakdown (Max) : 32V
Current - Collector (Ic) (Max) : 50mA
Current - DC Forward (If) (Max) : 50mA
Output Type : Phototransistor
Response Time : -
Mounting Type : Through Hole
Package / Case : PCB Mount
0
3922 in stock
