Seoul Semiconductor
- Seoul Semiconductor manufacturers and packages a wide selection of light emitting diodes (LEDs) for the automotive, lighting, appliance, mobile, signage, and back lighting units (BLU) markets. The company is the world’s fifth largest LED supplier, holding more than 10, 000 patents globally, while offering a wide range of LED technology and production capacity in areas such as "nPola", deep UV LEDs, and "Acrich", the world’s first commercially produced AC LED.
Part Number
Manufacturer
Description
Unit Price
In Stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 5100K (3200K ~ 7000K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 73 lm (61 lm ~ 85 lm)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 6.3V
Lumens/Watt @ Current - Test : 116 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 200mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1212 (3030 Metric)
Supplier Device Package : 3030
Size / Dimension : 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max) : 0.033" (0.85mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 2900K (2600K ~ 3200K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 73 lm (61 lm ~ 85 lm)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 6.3V
Lumens/Watt @ Current - Test : 116 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 200mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1212 (3030 Metric)
Supplier Device Package : 3030
Size / Dimension : 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max) : 0.033" (0.85mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 2900K (2600K ~ 3200K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 73 lm (61 lm ~ 85 lm)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 6.3V
Lumens/Watt @ Current - Test : 116 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 200mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1212 (3030 Metric)
Supplier Device Package : 3030
Size / Dimension : 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max) : 0.033" (0.85mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 5100K (3200K ~ 7000K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : -
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 6.3V
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : 80
Current - Max : 200mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1212 (3030 Metric)
Supplier Device Package : 3030
Size / Dimension : 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max) : 0.033" (0.85mm)
0
8169 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 5600K (5300K ~ 6000K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 73 lm (Typ)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 6.3V
Lumens/Watt @ Current - Test : 116 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 200mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1212 (3030 Metric)
Supplier Device Package : 3030
Size / Dimension : 0.118" L x 0.118" W (3.00mm x 3.00mm)
Height - Seated (Max) : 0.033" (0.85mm)
0
2613 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Acrich
Part Status : Obsolete
Color : White, Warm
CCT (K) : 3000K (2900K ~ 3200K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 30 lm (Typ)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.2V
Lumens/Watt @ Current - Test : 94 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : -
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.039" (1.00mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 2700K (2600K ~ 2900K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 31 lm (30 lm ~ 31 lm)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.2V
Lumens/Watt @ Current - Test : 97 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : -
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.039" (1.00mm)
0
152 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Discontinued at
Color : White
CCT (K) : -
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : -
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.15V
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : 80
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : 5630
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.039" (1.00mm)
0
3460 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3500K (3200K ~ 3700K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 33 lm (31 lm ~ 36 lm)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.2V
Lumens/Watt @ Current - Test : 103 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : -
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.039" (1.00mm)
0
415 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3500K (3200K ~ 3700K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 33 lm (31 lm ~ 36 lm)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.2V
Lumens/Watt @ Current - Test : 103 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : -
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.039" (1.00mm)
0
22 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Active
Color : White, Warm
CCT (K) : 3000K (2900K ~ 3200K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 35 lm (31 lm ~ 38 lm)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.2V
Lumens/Watt @ Current - Test : 109 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : -
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.039" (1.00mm)
0
1422 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 5000K (4700K ~ 5300K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 33 lm (Typ)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.2V
Lumens/Watt @ Current - Test : 103 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : -
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.039" (1.00mm)
0
100 in stock
