Sanken Electric Co., Ltd.
- Sanken Electric Co., Ltd., a leading global supplier of analog power semiconductor products, designs and manufactures a wide range of power management ICs, motor control ICs, LED lighting ICs as well as high quality automotive semiconductor devices and discrete components.
Part Number
Manufacturer
Description
Unit Price
In Stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
Motor Type - Stepper : Unipolar
Motor Type - AC, DC : -
Function : Driver - Fully Integrated, Control and Power Stage
Output Configuration : Half Bridge (2)
Interface : Parallel
Technology : Power MOSFET
Step Resolution : 1, 1/2
Applications : General Purpose
Current - Output : 2A
Voltage - Supply : 3 V ~ 5.5 V
Voltage - Load : 10 V ~ 44 V
Operating Temperature : -20°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 23-ESIP Formed Leads
Supplier Device Package : 23-ZIP w/fin
0
400 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
Motor Type - Stepper : Unipolar
Motor Type - AC, DC : -
Function : Driver - Fully Integrated, Control and Power Stage
Output Configuration : Half Bridge (2)
Interface : Parallel
Technology : Power MOSFET
Step Resolution : 1, 1/2
Applications : General Purpose
Current - Output : 3A
Voltage - Supply : 3 V ~ 5.5 V
Voltage - Load : 10 V ~ 44 V
Operating Temperature : -20°C ~ 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 23-ESIP Formed Leads
Supplier Device Package : 23-ZIP w/fin
0
73 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 PNP Darlington (Quad)
Current - Collector (Ic) (Max) : 3A
Voltage - Collector Emitter Breakdown (Max) : 60V
Vce Saturation (Max) @ Ib, Ic : 1.5V @ 4mA, 2A
Current - Collector Cutoff (Max) : 10µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 2000 @ 2A, 4V
Power - Max : 4W
Frequency - Transition : -
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP
0
69 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 NPN Darlington (Quad)
Current - Collector (Ic) (Max) : 3A
Voltage - Collector Emitter Breakdown (Max) : 100V
Vce Saturation (Max) @ Ib, Ic : 1.5V @ 3mA, 1.5A
Current - Collector Cutoff (Max) : 10µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 2000 @ 1.5A, 4V
Power - Max : 4W
Frequency - Transition : 40MHz
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP
0
2831 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 NPN Darlington (Quad)
Current - Collector (Ic) (Max) : 3A
Voltage - Collector Emitter Breakdown (Max) : 100V
Vce Saturation (Max) @ Ib, Ic : 1.5V @ 3mA, 1.5A
Current - Collector Cutoff (Max) : 10µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 2000 @ 1.5A, 4V
Power - Max : 4W
Frequency - Transition : 40MHz
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP
0
1305 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 NPN Darlington (Quad)
Current - Collector (Ic) (Max) : 2A
Voltage - Collector Emitter Breakdown (Max) : 100V
Vce Saturation (Max) @ Ib, Ic : 1.5V @ 2mA, 1A
Current - Collector Cutoff (Max) : 10µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 2000 @ 1A, 4V
Power - Max : 4W
Frequency - Transition : -
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP
0
2828 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 6 NPN Darlington
Current - Collector (Ic) (Max) : 2A
Voltage - Collector Emitter Breakdown (Max) : 120V
Vce Saturation (Max) @ Ib, Ic : 1.5V @ 2mA, 1A
Current - Collector Cutoff (Max) : 10µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 2000 @ 1A, 4V
Power - Max : 4W
Frequency - Transition : 50MHz
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 15-SIP Formed Leads
Supplier Device Package : 15-SIP
0
70 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 6 NPN Darlington
Current - Collector (Ic) (Max) : 3A
Voltage - Collector Emitter Breakdown (Max) : 120V
Vce Saturation (Max) @ Ib, Ic : 1.5V @ 3mA, 1.5A
Current - Collector Cutoff (Max) : 10µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 2000 @ 1.5A, 4V
Power - Max : 4W
Frequency - Transition : -
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 15-SIP Formed Leads
Supplier Device Package : 15-SIP
0
11 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
Transistor Type : 4 NPN Darlington (Quad)
Current - Collector (Ic) (Max) : 5A
Voltage - Collector Emitter Breakdown (Max) : 120V
Vce Saturation (Max) @ Ib, Ic : 1.5V @ 3mA, 3A
Current - Collector Cutoff (Max) : 10µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 2000 @ 3A, 2V
Power - Max : 5W
Frequency - Transition : -
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP
0
918 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 6 N-Channel (3-Phase Bridge)
FET Feature : Standard
Drain to Source Voltage (Vdss) : 250V
Current - Continuous Drain (Id) @ 25°C : 7A
Rds On (Max) @ Id, Vgs : 250 mOhm @ 3.5A, 10V
Vgs(th) (Max) @ Id : 4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 850pF @ 10V
Power - Max : 4W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP
0
100 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Active
FET Type : 6 N-Channel (3-Phase Bridge)
FET Feature : Standard
Drain to Source Voltage (Vdss) : 500V
Current - Continuous Drain (Id) @ 25°C : 5A
Rds On (Max) @ Id, Vgs : 1.4 Ohm @ 2.5A, 10V
Vgs(th) (Max) @ Id : 4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 770pF @ 10V
Power - Max : 4W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP
0
85 in stock
Sanken Electric Co., Ltd.
Manufacturer : Sanken
Packaging : Tube
Series : -
Part Status : Not For New Designs
FET Type : 3 N and 3 P-Channel (3-Phase Bridge)
FET Feature : Standard
Drain to Source Voltage (Vdss) : 60V
Current - Continuous Drain (Id) @ 25°C : 10A
Rds On (Max) @ Id, Vgs : 140 mOhm @ 5A, 4V
Vgs(th) (Max) @ Id : 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : -
Input Capacitance (Ciss) (Max) @ Vds : 460pF @ 10V
Power - Max : 4W
Operating Temperature : 150°C (TJ)
Mounting Type : Through Hole
Package / Case : 12-SIP
Supplier Device Package : 12-SIP
0
103 in stock
