Murata Power Solutions
- Murata Power Solutions designs and manufactures DC/DC Converters, AC/DC Power Supplies, Magnetics, Data Acquisition devices and Digital Panel Meters, and offers these products in custom, standard and modified-standard variations. Currently the world's number 1 supplier of DC/DC converters and one of the top 5 largest suppliers of power electronics overall, our products are used within numerous applications including telecommunications, computing, industrial, medical, office-equipment and more.
Murata Power Solutions was formed in 2007 when Murata Manufacturing Corporation acquired the power electronics division of C&D Technologies. We are headquartered in Mansfield, Massachusetts (USA) with over 1,300 employees in locations in the USA, Canada, Mexico, England, France, Germany, Japan, China and Singapore.
Part Number
Manufacturer
Description
Unit Price
In Stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4800S
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 33µH
Tolerance : ±20%
Current Rating : 2.8A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 73 mOhm Max
Q @ Freq : 31 @ 1MHz
Frequency - Self Resonant : 11MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.236" (6.00mm)
0
577 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4800S
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 330µH
Tolerance : ±20%
Current Rating : 850mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 630 mOhm Max
Q @ Freq : 22 @ 800kHz
Frequency - Self Resonant : 5MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.236" (6.00mm)
0
570 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4800S
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 3.3µH
Tolerance : ±30%
Current Rating : 7.3A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 12 mOhm Max
Q @ Freq : 34 @ 1MHz
Frequency - Self Resonant : 39MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.236" (6.00mm)
0
340 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4800
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 47µH
Tolerance : -
Current Rating : 1.8A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 274 mOhm max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.244" (6.20mm)
0
600 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4800
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 4.7µH
Tolerance : -
Current Rating : 5.7A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 29.4 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.244" (6.20mm)
0
93 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4800S
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 4.7µH
Tolerance : ±30%
Current Rating : 6.3A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 16 mOhm Max
Q @ Freq : 34 @ 1MHz
Frequency - Self Resonant : 28MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.236" (6.00mm)
0
595 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4800
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 68µH
Tolerance : -
Current Rating : 1.5A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 409 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.244" (6.20mm)
0
600 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4800S
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 68µH
Tolerance : ±20%
Current Rating : 1.8A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 145 mOhm Max
Q @ Freq : 33 @ 1MHz
Frequency - Self Resonant : 9MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.236" (6.00mm)
0
600 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4800S
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 6.8µH
Tolerance : ±30%
Current Rating : 5.1A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 21 mOhm Max
Q @ Freq : 34 @ 1MHz
Frequency - Self Resonant : 26MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.236" (6.00mm)
0
597 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4900
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 10µH
Tolerance : -
Current Rating : 4.5A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 41 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.472" L x 0.472" W (12.00mm x 12.00mm)
Height - Seated (Max) : 0.315" (8.00mm)
0
500 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4900S
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 10µH
Tolerance : ±20%
Current Rating : 5.1A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 21 mOhm Max
Q @ Freq : 43 @ 1MHz
Frequency - Self Resonant : 19MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.315" (8.00mm)
0
500 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 4900S
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 100µH
Tolerance : ±20%
Current Rating : 1.6A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 165 mOhm Max
Q @ Freq : 40 @ 800kHz
Frequency - Self Resonant : 6MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 10kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard, 4 Lead
Supplier Device Package : -
Size / Dimension : 0.480" L x 0.480" W (12.20mm x 12.20mm)
Height - Seated (Max) : 0.315" (8.00mm)
0
1500 in stock
