Murata Power Solutions
- Murata Power Solutions designs and manufactures DC/DC Converters, AC/DC Power Supplies, Magnetics, Data Acquisition devices and Digital Panel Meters, and offers these products in custom, standard and modified-standard variations. Currently the world's number 1 supplier of DC/DC converters and one of the top 5 largest suppliers of power electronics overall, our products are used within numerous applications including telecommunications, computing, industrial, medical, office-equipment and more.
Murata Power Solutions was formed in 2007 when Murata Manufacturing Corporation acquired the power electronics division of C&D Technologies. We are headquartered in Mansfield, Massachusetts (USA) with over 1,300 employees in locations in the USA, Canada, Mexico, England, France, Germany, Japan, China and Singapore.
Part Number
Manufacturer
Description
Unit Price
In Stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2400
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 33µH
Tolerance : -
Current Rating : 900mA
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 190 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 11.2MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.303" L x 0.280" W (7.70mm x 7.10mm)
Height - Seated (Max) : 0.177" (4.50mm)
0
1000 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2400
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 4.7µH
Tolerance : -
Current Rating : 2.39A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 37 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 52MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.303" L x 0.280" W (7.70mm x 7.10mm)
Height - Seated (Max) : 0.177" (4.50mm)
0
1000 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2400
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 6.8µH
Tolerance : -
Current Rating : 2A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 45 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 39MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.303" L x 0.280" W (7.70mm x 7.10mm)
Height - Seated (Max) : 0.177" (4.50mm)
0
1000 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2600
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 100µH
Tolerance : -
Current Rating : 970mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 350 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 6.56MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) : 0.228" (5.80mm)
0
495 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2600
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 150µH
Tolerance : -
Current Rating : 780mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 470 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 5.2MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) : 0.228" (5.80mm)
0
500 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2600
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 18µH
Tolerance : -
Current Rating : 2.1A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 87 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 19MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) : 0.228" (5.80mm)
0
500 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2600
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 220µH
Tolerance : -
Current Rating : 660mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 730 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 4MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) : 0.228" (5.80mm)
0
500 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2600
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 470µH
Tolerance : -
Current Rating : 420mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 1.48 Ohm Max
Q @ Freq : -
Frequency - Self Resonant : 2.54MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) : 0.228" (5.80mm)
0
500 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2600
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 4.7µH
Tolerance : -
Current Rating : 3.6A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 45 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 37MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) : 0.228" (5.80mm)
0
459 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2600
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 68µH
Tolerance : -
Current Rating : 1.11A
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 220 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 8.37MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) : 0.228" (5.80mm)
0
500 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2600
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 680µH
Tolerance : -
Current Rating : 280mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 2.25 Ohm Max
Q @ Freq : -
Frequency - Self Resonant : 1.97MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.394" L x 0.354" W (10.00mm x 9.00mm)
Height - Seated (Max) : 0.228" (5.80mm)
0
500 in stock
Murata Power Solutions
Manufacturer : Murata Power Solutions Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 2600
Part Status : Active
Type : Wirewound
Material - Core : -
Inductance : 100µH
Tolerance : -
Current Rating : 1.05A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 250 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : 6.04MHz
Ratings : -
Operating Temperature : -40°C ~ 85°C
Inductance Frequency - Test : 1kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.496" L x 0.181" W (12.60mm x 4.60mm)
Height - Seated (Max) : 0.232" (5.90mm)
0
500 in stock
