Luminus Devices, Inc.
- Luminus Devices, Inc. develops and markets solid-state lighting solutions (SSL) to help its customers migrate from conventional lamp technologies to long-life and energy-efficient LED illumination. Luminus offers a comprehensive range of LED solutions for indoor and outdoor illumination markets as well as high-output specialty lighting solutions for performance-driven markets including consumer displays, entertainment lighting, medical and industrial applications. Luminus is headquartered in Sunnyvale, CA, and has operations in Woburn, Massachusetts and Xiamen, China.
Part Number
Manufacturer
Description
Unit Price
In Stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : -
Series : CBT-120
Part Status : Discontinued at
Type : LED Module
Color : Red
CCT (K) : -
Wavelength : 623nm (611nm ~ 635nm)
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 18A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 2.3V
Lumens/Watt @ Current - Test : -
Current - Max : 36A
CRI (Color Rendering Index) : -
Viewing Angle : -
Features : With Connector
Size / Dimension : 28.00mm L x 42.00mm W
Height : 5.61mm
Light Emitting Surface (LES) : 2.60mm L x 4.63mm W
Lens Type : Flat
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : -
Series : CBT-120
Part Status : Discontinued at
Type : LED Module
Color : Red
CCT (K) : -
Wavelength : 621nm (619nm ~ 623nm)
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 18A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 2.3V
Lumens/Watt @ Current - Test : -
Current - Max : 36A
CRI (Color Rendering Index) : -
Viewing Angle : -
Features : With Connector
Size / Dimension : 28.00mm L x 42.00mm W
Height : 5.61mm
Light Emitting Surface (LES) : 2.60mm L x 4.63mm W
Lens Type : Flat
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : -
Part Status : Obsolete
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 30A
Radiant Intensity (Ie) Min @ If : -
Wavelength : 382nm
Voltage - Forward (Vf) (Typ) : 3.7V
Viewing Angle : -
Orientation : Top View
Operating Temperature : 150°C (TJ)
Mounting Type : Chassis Mount
Package / Case : Module
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : -
Part Status : Obsolete
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 30A
Radiant Intensity (Ie) Min @ If : -
Wavelength : 382nm
Voltage - Forward (Vf) (Typ) : 3.7V
Viewing Angle : -
Orientation : Top View
Operating Temperature : 150°C (TJ)
Mounting Type : Chassis Mount
Package / Case : Module
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : -
Part Status : Obsolete
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 30A
Radiant Intensity (Ie) Min @ If : -
Wavelength : 382nm
Voltage - Forward (Vf) (Typ) : 3.7V
Viewing Angle : -
Orientation : Top View
Operating Temperature : 150°C (TJ)
Mounting Type : Chassis Mount
Package / Case : Module
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : -
Part Status : Obsolete
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 30A
Radiant Intensity (Ie) Min @ If : -
Wavelength : 382nm
Voltage - Forward (Vf) (Typ) : 3.7V
Viewing Angle : -
Orientation : Top View
Operating Temperature : 150°C (TJ)
Mounting Type : Chassis Mount
Package / Case : Module
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : -
Part Status : Obsolete
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 30A
Radiant Intensity (Ie) Min @ If : -
Wavelength : 382nm
Voltage - Forward (Vf) (Typ) : 3.7V
Viewing Angle : -
Orientation : Top View
Operating Temperature : 150°C (TJ)
Mounting Type : Chassis Mount
Package / Case : Module
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : -
Part Status : Obsolete
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 30A
Radiant Intensity (Ie) Min @ If : -
Wavelength : 382nm
Voltage - Forward (Vf) (Typ) : 3.7V
Viewing Angle : -
Orientation : Top View
Operating Temperature : 150°C (TJ)
Mounting Type : Chassis Mount
Package / Case : Module
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : -
Part Status : Active
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 30A
Radiant Intensity (Ie) Min @ If : -
Wavelength : 400nm
Voltage - Forward (Vf) (Typ) : 3.4V
Viewing Angle : -
Orientation : Top View
Operating Temperature : 150°C (TJ)
Mounting Type : Chassis Mount
Package / Case : Module
0
1 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : -
Part Status : Active
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 30A
Radiant Intensity (Ie) Min @ If : -
Wavelength : 400nm
Voltage - Forward (Vf) (Typ) : 3.4V
Viewing Angle : -
Orientation : Top View
Operating Temperature : 150°C (TJ)
Mounting Type : Chassis Mount
Package / Case : Module
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : -
Part Status : Obsolete
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 30A
Radiant Intensity (Ie) Min @ If : -
Wavelength : 382nm
Voltage - Forward (Vf) (Typ) : 3.7V
Viewing Angle : -
Orientation : Top View
Operating Temperature : 150°C (TJ)
Mounting Type : Screw Mount
Package / Case : Module
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : -
Part Status : Obsolete
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 30A
Radiant Intensity (Ie) Min @ If : -
Wavelength : 382nm
Voltage - Forward (Vf) (Typ) : 3.7V
Viewing Angle : -
Orientation : Top View
Operating Temperature : 150°C (TJ)
Mounting Type : Screw Mount
Package / Case : Module
0
100 in stock
