Inventus Power
- Inventus Power, formerly ICCNexergy + Palladium Energy, is the world’s ONLY power systems manufacturer that integrates and delivers battery packs, chargers & docking stations and power supplies across the consumer, commercial, medical and military & government markets and is located in 8 countries across 4 continents.
Inventus Power has almost 60 years of experience designing high quality medical power supplies and commercial AC/DC power supplies. Our standard Elpac offering of desktop and open frame power supplies ranges from 5W to 350W and we have custom developed power supplies up to 2000 watts. We demonstrate MTBF on all power systems by conducting extensive in-house life testing (High Temp, High Stress, 100% Burn-In, etc.). Our proven design guidelines allow us to offer an industry-best five year warranty on all of our standard Elpac power solutions.
Part Number
Manufacturer
Description
Unit Price
In Stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW18 (18W)
Part Status : Obsolete
Region Utilized : International
Form : Desktop (Class I)
Input Type : Cord (Sold Separately)
Voltage - Input : 100 ~ 240 VAC
Voltage - Output : 24V
Current - Output (Max) : 750mA
Power (Watts) : 18W
No Load Power Consumption : -
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 80%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 3.35" L x 1.97" W x 1.30" H (85.0mm x 50.0mm x 33.0mm)
Approvals : -
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW30 (30W)
Part Status : Obsolete
Region Utilized : North America
Form : Desktop (Class I)
Input Type : Cord
Voltage - Input : 100 ~ 240 VAC
Voltage - Output : 12V
Current - Output (Max) : 2.5A
Power (Watts) : 30W
No Load Power Consumption : -
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 80%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 4.25" L x 2.50" W x 1.30" H (108.0mm x 64.5mm x 33.0mm)
Approvals : -
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW30 (30W)
Part Status : Obsolete
Region Utilized : North America
Form : Desktop (Class I)
Input Type : Cord
Voltage - Input : 85 ~ 264 VAC
Voltage - Output : 12V
Current - Output (Max) : 2.4A
Power (Watts) : 29W
No Load Power Consumption : 300mW (Max)
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 83%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 4.31" L x 2.54" W x 1.30" H (109.6mm x 64.5mm x 33.0mm)
Approvals : CB, CE, cULus, TUVgs
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW30 (30W)
Part Status : Obsolete
Region Utilized : International
Form : Desktop (Class I)
Input Type : Cord (Sold Separately)
Voltage - Input : 100 ~ 240 VAC
Voltage - Output : 12V
Current - Output (Max) : 2.5A
Power (Watts) : 30W
No Load Power Consumption : -
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 80%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 4.25" L x 2.50" W x 1.30" H (108.0mm x 64.5mm x 33.0mm)
Approvals : -
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW30 (30W)
Part Status : Obsolete
Region Utilized : North America
Form : Desktop (Class I)
Input Type : Cord
Voltage - Input : 100 ~ 240 VAC
Voltage - Output : 15V
Current - Output (Max) : 2A
Power (Watts) : 30W
No Load Power Consumption : -
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 80%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 4.25" L x 2.50" W x 1.30" H (108.0mm x 64.5mm x 33.0mm)
Approvals : -
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW30 (30W)
Part Status : Obsolete
Region Utilized : North America
Form : Desktop (Class I)
Input Type : Cord
Voltage - Input : 85 ~ 264 VAC
Voltage - Output : 15V
Current - Output (Max) : 2A
Power (Watts) : 30W
No Load Power Consumption : 300mW (Max)
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 84%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 4.31" L x 2.54" W x 1.30" H (109.6mm x 64.5mm x 33.0mm)
Approvals : CB, CE, cULus, TUVgs
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW30 (30W)
Part Status : Obsolete
Region Utilized : International
Form : Desktop (Class I)
Input Type : Cord (Sold Separately)
Voltage - Input : 100 ~ 240 VAC
Voltage - Output : 15V
Current - Output (Max) : 2A
Power (Watts) : 30W
No Load Power Consumption : -
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 80%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 4.25" L x 2.50" W x 1.30" H (108.0mm x 64.5mm x 33.0mm)
Approvals : -
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW30 (30W)
Part Status : Obsolete
Region Utilized : North America
Form : Desktop (Class I)
Input Type : Cord
Voltage - Input : 100 ~ 240 VAC
Voltage - Output : 24V
Current - Output (Max) : 1.25A
Power (Watts) : 30W
No Load Power Consumption : -
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 80%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 4.25" L x 2.50" W x 1.30" H (108.0mm x 64.5mm x 33.0mm)
Approvals : -
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW30 (30W)
Part Status : Obsolete
Region Utilized : North America
Form : Desktop (Class I)
Input Type : Cord
Voltage - Input : 85 ~ 264 VAC
Voltage - Output : 24V
Current - Output (Max) : 1.5A
Power (Watts) : 36W
No Load Power Consumption : 300mW (Max)
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 86%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 4.31" L x 2.54" W x 1.30" H (109.6mm x 64.5mm x 33.0mm)
Approvals : CB, CE, cULus, TUVgs
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW30 (30W)
Part Status : Obsolete
Region Utilized : International
Form : Desktop (Class I)
Input Type : Cord (Sold Separately)
Voltage - Input : 100 ~ 240 VAC
Voltage - Output : 24V
Current - Output (Max) : 1.25A
Power (Watts) : 30W
No Load Power Consumption : -
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 80%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 4.25" L x 2.50" W x 1.30" H (108.0mm x 64.5mm x 33.0mm)
Approvals : -
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW50 (50W)
Part Status : Obsolete
Region Utilized : North America
Form : Desktop (Class I)
Input Type : Cord
Voltage - Input : 100 ~ 240 VAC
Voltage - Output : 12V
Current - Output (Max) : 4.15A
Power (Watts) : 50W
No Load Power Consumption : -
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 80%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 5.00" L x 3.00" W x 1.30" H (127.0mm x 76.2mm x 33.0mm)
Approvals : -
0
100 in stock
ICCNexergy (Inventus Power)
Manufacturer : Inventus Power
Series : FW50 (50W)
Part Status : Obsolete
Region Utilized : North America
Form : Desktop (Class I)
Input Type : Cord
Voltage - Input : 85 ~ 264 VAC
Voltage - Output : 12V
Current - Output (Max) : 4.15A
Power (Watts) : 50W
No Load Power Consumption : 300mW (Max)
Polarization : Positive Center
Applications : ITE (Commercial)
Efficiency : 83%
Operating Temperature : 0°C ~ 60°C
Output Connector : Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm
Size / Dimension : 5.00" L x 3.00" W x 1.30" H (127.0mm x 76.2mm x 33.0mm)
Approvals : CCC, CE, cULus, TUVgs
0
100 in stock
