Global Power Technologies Group, Inc.
- Global Power Technologies Group, Inc. (“GPTG”) founded in 2007 is an integrated development and manufacturing company dedicated to products based on Silicon Carbide (SiC) technologies. These products will be foundational to the power electronics and energy industries in future years where advanced technologies are needed for low cost, highly efficient power generation, conversion and transmission.
Part Number
Manufacturer
Description
Unit Price
In Stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 650V
Current - Average Rectified (Io) : 3A
Voltage - Forward (Vf) (Max) @ If : 1.65V @ 3A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 200µA @ 650V
Capacitance @ Vr, F : 158pF @ 1V, 1MHz
Mounting Type : Surface Mount
Package / Case : TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package : TO-252-2L (DPAK)
Operating Temperature - Junction : -55°C ~ 175°C
0
358 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 600V
Current - Average Rectified (Io) : 15A (DC)
Voltage - Forward (Vf) (Max) @ If : 1.65V @ 5A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 20µA @ 600V
Capacitance @ Vr, F : 264pF @ 1V, 1MHz
Mounting Type : Through Hole
Package / Case : TO-220-2
Supplier Device Package : TO-220-2
Operating Temperature - Junction : -50°C ~ 175°C
0
55 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Discontinued at
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 1200V
Current - Average Rectified (Io) : 5A (DC)
Voltage - Forward (Vf) (Max) @ If : 1.8V @ 5A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 10µA @ 1200V
Capacitance @ Vr, F : 317pF @ 1V, 1MHz
Mounting Type : Through Hole
Package / Case : TO-220-2
Supplier Device Package : TO-220-2
Operating Temperature - Junction : -55°C ~ 175°C
0
764 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Discontinued at
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 1700V
Current - Average Rectified (Io) : 5A (DC)
Voltage - Forward (Vf) (Max) @ If : 1.75V @ 5A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 10µA @ 1700V
Capacitance @ Vr, F : 406pF @ 1V, 1MHz
Mounting Type : Through Hole
Package / Case : TO-247-2
Supplier Device Package : TO-247-2
Operating Temperature - Junction : -55°C ~ 175°C
0
493 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 600V
Current - Average Rectified (Io) : 6A (DC)
Voltage - Forward (Vf) (Max) @ If : 1.65V @ 6A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 20µA @ 600V
Capacitance @ Vr, F : 316pF @ 1V, 1MHz
Mounting Type : Through Hole
Package / Case : TO-220-2
Supplier Device Package : TO-220-2
Operating Temperature - Junction : -55°C ~ 175°C
0
2137 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 600V
Current - Average Rectified (Io) : 6A (DC)
Voltage - Forward (Vf) (Max) @ If : 1.65V @ 6A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 20µA @ 600V
Capacitance @ Vr, F : 316pF @ 1V, 1MHz
Mounting Type : Surface Mount
Package / Case : TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package : TO-252-2L (DPAK)
Operating Temperature - Junction : -55°C ~ 175°C
0
404 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 650V
Current - Average Rectified (Io) : 6A
Voltage - Forward (Vf) (Max) @ If : 1.65V @ 6A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 60µA @ 650V
Capacitance @ Vr, F : 316pF @ 1V, 1MHz
Mounting Type : Through Hole
Package / Case : TO-220-2
Supplier Device Package : TO-220-2
Operating Temperature - Junction : -55°C ~ 175°C
0
89 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 650V
Current - Average Rectified (Io) : 6A (DC)
Voltage - Forward (Vf) (Max) @ If : 1.65V @ 6A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 60µA @ 650V
Capacitance @ Vr, F : 316pF @ 1V, 1MHz
Mounting Type : Surface Mount
Package / Case : TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package : TO-252-2L (DPAK)
Operating Temperature - Junction : -55°C ~ 175°C
0
376 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 1200V
Current - Average Rectified (Io) : 24A (DC)
Voltage - Forward (Vf) (Max) @ If : 1.8V @ 8A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 20µA @ 1200V
Capacitance @ Vr, F : 508pF @ 1V, 1MHz
Mounting Type : Surface Mount
Package / Case : TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package : TO-252-2L (DPAK)
Operating Temperature - Junction : -50°C ~ 175°C
0
59 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 1200V
Current - Average Rectified (Io) : 10A
Voltage - Forward (Vf) (Max) @ If : 1.8V @ 10A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 20µA @ 1200V
Capacitance @ Vr, F : 635pF @ 1V, 1MHz
Mounting Type : Through Hole
Package / Case : TO-220-2
Supplier Device Package : TO-220-2
Operating Temperature - Junction : -55°C ~ 175°C
0
759 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 1200V
Current - Average Rectified (Io) : 10A
Voltage - Forward (Vf) (Max) @ If : 1.8V @ 10A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 20µA @ 1200V
Capacitance @ Vr, F : 635pF @ 1V, 1MHz
Mounting Type : Through Hole
Package / Case : TO-247-2
Supplier Device Package : TO-247-2
Operating Temperature - Junction : -55°C ~ 175°C
0
505 in stock
Global Power Technologies Group
Manufacturer : Global Power Technologies Group
Packaging : Tube
Series : Amp+™
Part Status : Active
Diode Type : Silicon Carbide Schottky
Voltage - DC Reverse (Vr) (Max) : 600V
Current - Average Rectified (Io) : 12A
Voltage - Forward (Vf) (Max) @ If : 1.65V @ 12A
Speed : No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr) : 0ns
Current - Reverse Leakage @ Vr : 40µA @ 600V
Capacitance @ Vr, F : 632pF @ 1V, 1MHz
Mounting Type : Through Hole
Package / Case : TO-220-2
Supplier Device Package : TO-220-2
Operating Temperature - Junction : -55°C ~ 175°C
0
1246 in stock
