Citizen Electronics Co., Ltd.

- Born out of the Citizen Watch Company and its need to develop state-of-the-art micro-miniature electronic components, Citizen has grown beyond to become a technology leader in key components for today's most advanced products. Their packaging technology brings more flexibility in downsizing your design and application. They are helping leading-edge makers of PDAs, digital cameras, automotive products, measurement instruments, lighting apparatus and others to better interface between human and machine. Citizen's surface mountable LED products, switches and sensors are raising the bar for performance and design creativity.

Part Number
Manufacturer
Description
Unit Price
In Stock

CLU048-1812C4-403M2K1 CLU048-1812C4-403M2K1

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 8392 lm (Typ)
Current - Test : 1.08A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 149 lm/W
Current - Max : 2.76A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
52 in stock

CLU048-1812C4-40AL7K3 CLU048-1812C4-40AL7K3

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 8883 lm (Typ)
Current - Test : 1.08A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 158 lm/W
Current - Max : 2.76A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
20 in stock

CLU048-1818C4-273H5K2 CLU048-1818C4-273H5K2

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 2700K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 9391 lm (Typ)
Current - Test : 1.62A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 111 lm/W
Current - Max : 4.14A
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
30 in stock

CLU048-1818C4-273M2K1 CLU048-1818C4-273M2K1

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 2700K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 11367 lm (Typ)
Current - Test : 1.62A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 135 lm/W
Current - Max : 4.14A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
23 in stock

CLU048-1818C4-303H5K2 CLU048-1818C4-303H5K2

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 9815 lm (Typ)
Current - Test : 1.62A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 117 lm/W
Current - Max : 4.14A
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
54 in stock

CLU048-1818C4-303M2K1 CLU048-1818C4-303M2K1

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 11881 lm (Typ)
Current - Test : 1.62A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 141 lm/W
Current - Max : 4.14A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
25 in stock

CLU048-1818C4-353H5K2 CLU048-1818C4-353H5K2

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3500K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 10003 lm (Typ)
Current - Test : 1.62A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 119 lm/W
Current - Max : 4.14A
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
30 in stock

CLU048-1818C4-353M2K1 CLU048-1818C4-353M2K1

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3500K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 12121 lm (Typ)
Current - Test : 1.62A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 144 lm/W
Current - Max : 4.14A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
100 in stock

CLU048-1818C4-403H5K2 CLU048-1818C4-403H5K2

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 10108 lm (Typ)
Current - Test : 1.62A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 120 lm/W
Current - Max : 4.14A
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
23 in stock

CLU048-1818C4-403M2K1 CLU048-1818C4-403M2K1

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 12249 lm (Typ)
Current - Test : 1.62A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 145 lm/W
Current - Max : 4.14A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
53 in stock

CLU048-1818C4-40AL7K3 CLU048-1818C4-40AL7K3

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 12965 lm (Typ)
Current - Test : 1.62A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 154 lm/W
Current - Max : 4.14A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
22 in stock

CLU048-1818C4-50AL7K3 CLU048-1818C4-50AL7K3

Citizen Electronics Co., Ltd.
Manufacturer : Citizen
Packaging : Tray
Series : CLU048
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 13162 lm (Typ)
Current - Test : 1.62A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 52V
Lumens/Watt @ Current - Test : 156 lm/W
Current - Max : 4.14A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : -
Size / Dimension : 28.00mm L x 28.00mm W
Height : 1.40mm
Light Emitting Surface (LES) : 22.00mm Diameter
Lens Type : Flat
0
57 in stock
