Part Number
Manufacturer
Description
Unit Price
In Stock
146F
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 250CT
Impedance - Secondary (Ohms) : 3.2
DC Resistance (DCR) - Primary : 11 Ohm
DC Resistance (DCR) - Secondary : 300 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 250CT
Impedance - Secondary (Ohms) : 3.2
DC Resistance (DCR) - Primary : 11 Ohm
DC Resistance (DCR) - Secondary : 300 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
0
19 in stock
146G
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 250CT
Impedance - Secondary (Ohms) : 8
DC Resistance (DCR) - Primary : 11 Ohm
DC Resistance (DCR) - Secondary : 700 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 250CT
Impedance - Secondary (Ohms) : 8
DC Resistance (DCR) - Primary : 11 Ohm
DC Resistance (DCR) - Secondary : 700 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
0
20 in stock
146H
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 500CT
Impedance - Secondary (Ohms) : 3.2
DC Resistance (DCR) - Primary : 26 Ohm
DC Resistance (DCR) - Secondary : 300 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 500CT
Impedance - Secondary (Ohms) : 3.2
DC Resistance (DCR) - Primary : 26 Ohm
DC Resistance (DCR) - Secondary : 300 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
0
6 in stock
146I
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 500CT
Impedance - Secondary (Ohms) : 8
DC Resistance (DCR) - Primary : 26 Ohm
DC Resistance (DCR) - Secondary : 700 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 500CT
Impedance - Secondary (Ohms) : 8
DC Resistance (DCR) - Primary : 26 Ohm
DC Resistance (DCR) - Secondary : 700 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
0
12 in stock
146J
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 1kCT
Impedance - Secondary (Ohms) : 3.2
DC Resistance (DCR) - Primary : 56 Ohm
DC Resistance (DCR) - Secondary : 300 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 1kCT
Impedance - Secondary (Ohms) : 3.2
DC Resistance (DCR) - Primary : 56 Ohm
DC Resistance (DCR) - Secondary : 300 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
0
5 in stock
146K
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 1kCT
Impedance - Secondary (Ohms) : 8
DC Resistance (DCR) - Primary : 56 Ohm
DC Resistance (DCR) - Secondary : 700 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 1kCT
Impedance - Secondary (Ohms) : 8
DC Resistance (DCR) - Primary : 56 Ohm
DC Resistance (DCR) - Secondary : 700 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
0
4 in stock
146N
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 2kCT
Impedance - Secondary (Ohms) : 8
DC Resistance (DCR) - Primary : 97 Ohm
DC Resistance (DCR) - Secondary : 700 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 2kCT
Impedance - Secondary (Ohms) : 8
DC Resistance (DCR) - Primary : 97 Ohm
DC Resistance (DCR) - Secondary : 700 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
0
5 in stock
146S
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 4kCT
Impedance - Secondary (Ohms) : 8
DC Resistance (DCR) - Primary : 220 Ohm
DC Resistance (DCR) - Secondary : 700 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
Packaging : Bulk
Series : 146
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 4kCT
Impedance - Secondary (Ohms) : 8
DC Resistance (DCR) - Primary : 220 Ohm
DC Resistance (DCR) - Secondary : 700 mOhm
Transformer Type : Economical Open Type
Frequency Range : 150Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : -
Return Loss : -
Power Level : 700mW
Operating Temperature : -
Approvals : -
Mounting Type : Chassis Mount
Size / Dimension : 1.630" L x 0.880" W (41.40mm x 22.35mm)
Height - Seated (Max) : 0.810" (20.57mm)
Termination Style : Wire Leads
0
19 in stock
148A
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 148
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 600, 150/150
Impedance - Secondary (Ohms) : 2.4k, 600/600
DC Resistance (DCR) - Primary : 45 Ohm
DC Resistance (DCR) - Secondary : 300 Ohm
Transformer Type : Economical Open Type
Frequency Range : 200Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : 0.5dB
Return Loss : -
Power Level : 300mW
Operating Temperature : -
Approvals : -
Mounting Type : Through Hole
Size / Dimension : 0.820" L x 0.680" W (20.83mm x 17.27mm)
Height - Seated (Max) : 0.690" (17.53mm)
Termination Style : PC Pin
Packaging : Bulk
Series : 148
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 600, 150/150
Impedance - Secondary (Ohms) : 2.4k, 600/600
DC Resistance (DCR) - Primary : 45 Ohm
DC Resistance (DCR) - Secondary : 300 Ohm
Transformer Type : Economical Open Type
Frequency Range : 200Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : 0.5dB
Return Loss : -
Power Level : 300mW
Operating Temperature : -
Approvals : -
Mounting Type : Through Hole
Size / Dimension : 0.820" L x 0.680" W (20.83mm x 17.27mm)
Height - Seated (Max) : 0.690" (17.53mm)
Termination Style : PC Pin
0
16 in stock
148B
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 148
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 150
Impedance - Secondary (Ohms) : 1.6k, 400/400
DC Resistance (DCR) - Primary : 11.3 Ohm
DC Resistance (DCR) - Secondary : 200 Ohm
Transformer Type : Economical Open Type
Frequency Range : 200Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : 0.5dB
Return Loss : -
Power Level : 300mW
Operating Temperature : -
Approvals : -
Mounting Type : Through Hole
Size / Dimension : 0.820" L x 0.680" W (20.83mm x 17.27mm)
Height - Seated (Max) : 0.690" (17.53mm)
Termination Style : PC Pin
Packaging : Bulk
Series : 148
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 150
Impedance - Secondary (Ohms) : 1.6k, 400/400
DC Resistance (DCR) - Primary : 11.3 Ohm
DC Resistance (DCR) - Secondary : 200 Ohm
Transformer Type : Economical Open Type
Frequency Range : 200Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : 0.5dB
Return Loss : -
Power Level : 300mW
Operating Temperature : -
Approvals : -
Mounting Type : Through Hole
Size / Dimension : 0.820" L x 0.680" W (20.83mm x 17.27mm)
Height - Seated (Max) : 0.690" (17.53mm)
Termination Style : PC Pin
0
18 in stock
148C
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 148
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 50k
Impedance - Secondary (Ohms) : 1k, 250/250
DC Resistance (DCR) - Primary : 1.76 kOhm
DC Resistance (DCR) - Secondary : 25.4 Ohm
Transformer Type : Economical Open Type
Frequency Range : 200Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : 0.5dB
Return Loss : -
Power Level : 12mW
Operating Temperature : -
Approvals : -
Mounting Type : Through Hole
Size / Dimension : 0.820" L x 0.680" W (20.83mm x 17.27mm)
Height - Seated (Max) : 0.690" (17.53mm)
Termination Style : PC Pin
Packaging : Bulk
Series : 148
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 50k
Impedance - Secondary (Ohms) : 1k, 250/250
DC Resistance (DCR) - Primary : 1.76 kOhm
DC Resistance (DCR) - Secondary : 25.4 Ohm
Transformer Type : Economical Open Type
Frequency Range : 200Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : 0.5dB
Return Loss : -
Power Level : 12mW
Operating Temperature : -
Approvals : -
Mounting Type : Through Hole
Size / Dimension : 0.820" L x 0.680" W (20.83mm x 17.27mm)
Height - Seated (Max) : 0.690" (17.53mm)
Termination Style : PC Pin
0
9 in stock
148D
Hammond Manufacturing
Manufacturer : Hammond Manufacturing
Packaging : Bulk
Series : 148
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 200k
Impedance - Secondary (Ohms) : 1k
DC Resistance (DCR) - Primary : 1.76 kOhm
DC Resistance (DCR) - Secondary : 6.2 Ohm
Transformer Type : Economical Open Type
Frequency Range : 200Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : 0.5dB
Return Loss : -
Power Level : 3mW
Operating Temperature : -
Approvals : -
Mounting Type : Through Hole
Size / Dimension : 0.820" L x 0.680" W (20.83mm x 17.27mm)
Height - Seated (Max) : 0.690" (17.53mm)
Termination Style : PC Pin
Packaging : Bulk
Series : 148
Part Status : Active
Turns Ratio - Primary:Secondary : -
Impedance - Primary (Ohms) : 200k
Impedance - Secondary (Ohms) : 1k
DC Resistance (DCR) - Primary : 1.76 kOhm
DC Resistance (DCR) - Secondary : 6.2 Ohm
Transformer Type : Economical Open Type
Frequency Range : 200Hz ~ 15kHz
Frequency Response : ±1dB
Voltage - Isolation : -
Insertion Loss : 0.5dB
Return Loss : -
Power Level : 3mW
Operating Temperature : -
Approvals : -
Mounting Type : Through Hole
Size / Dimension : 0.820" L x 0.680" W (20.83mm x 17.27mm)
Height - Seated (Max) : 0.690" (17.53mm)
Termination Style : PC Pin
0
11 in stock
New Original Stock
Competitive Prices
One-stop
Customer Service
Contact Weijie
- sales@ynnelec.com
- jay@ynnelec.com
- 1132 Nanguang Jiejia Building, No. 3037 Shennan Middle Road, Futian District, Shenzhen
Customer service
Copyright © 2024 Ynnelec. All rights reserved.
webdesign www.wzdzkf.com
Powered by www.wzdzkf.com
