ACNT-H313-000E
ACNT-H313-000E
Manufacturer : Broadcom Limited
Packaging : Tube
Series : -
Part Status : Active
Technology : Optical Coupling
Number of Channels : 1
Voltage - Isolation : 7500Vrms
Common Mode Transient Immunity (Min) : 40kV/µs
Propagation Delay tpLH / tpHL (Max) : 500ns, 500ns
Pulse Width Distortion (Max) : 300ns
Rise / Fall Time (Typ) : 100ns, 100ns
Current - Output High, Low : 2A, 2A
Current - Peak Output : 2.5A
Voltage - Forward (Vf) (Typ) : 1.45V
Current - DC Forward (If) (Max) : 25mA
Voltage - Supply : 15 V ~ 30 V
Operating Temperature : -40°C ~ 105°C
Mounting Type : Surface Mount
Package / Case : 8-SOIC (0.543", 13.80mm Width)
Supplier Device Package : 8-SO
Approvals : CSA, IEC/EN/DIN, UR
Availability: 1124 in stock
