QT Brightek
- QT Brightek is headquartered in the San Francisco bay area with sales, marketing and field application support throughout the Americas, Europe and Asia. The product families offered are SMT LED, thru-hole LEDs, LED displayss, optocoupler, IR devices, and custom modules.
Part Number
Manufacturer
Description
Unit Price
In Stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : QBPH684E-UV
Part Status : Active
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 385nm
Voltage - Forward (Vf) (Typ) : 3.4V
Viewing Angle : 60°
Orientation : Top View
Operating Temperature : -40°C ~ 80°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
443 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : QBPH684E-UV
Part Status : Discontinued at
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 385nm
Voltage - Forward (Vf) (Typ) : 3.4V
Viewing Angle : 120°
Orientation : Top View
Operating Temperature : -40°C ~ 80°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
100 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : QBPH684E-UV
Part Status : Active
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 395nm
Voltage - Forward (Vf) (Typ) : 3.4V
Viewing Angle : 60°
Orientation : Top View
Operating Temperature : -40°C ~ 80°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
362 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : QBPH684E-UV
Part Status : Active
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 395nm
Voltage - Forward (Vf) (Typ) : 3.4V
Viewing Angle : 120°
Orientation : Top View
Operating Temperature : -40°C ~ 80°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
989 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : QBPH684E-UV
Part Status : Active
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 405nm
Voltage - Forward (Vf) (Typ) : 3.4V
Viewing Angle : 60°
Orientation : Top View
Operating Temperature : -40°C ~ 80°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
145 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : QBPH684E-UV
Part Status : Active
Type : Ultraviolet (UV)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 405nm
Voltage - Forward (Vf) (Typ) : 3.4V
Viewing Angle : 120°
Orientation : Top View
Operating Temperature : -40°C ~ 80°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
993 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Infrared (IR)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 940nm
Voltage - Forward (Vf) (Typ) : 1.7V
Viewing Angle : 60°
Orientation : Top View
Operating Temperature : -40°C ~ 85°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
232 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Infrared (IR)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 940nm
Voltage - Forward (Vf) (Typ) : 1.7V
Viewing Angle : 120°
Orientation : Top View
Operating Temperature : -40°C ~ 85°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
160 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Infrared (IR)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 850nm
Voltage - Forward (Vf) (Typ) : 1.9V
Viewing Angle : 60°
Orientation : Top View
Operating Temperature : -40°C ~ 85°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
270 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Infrared (IR)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 740nm
Voltage - Forward (Vf) (Typ) : 1.9V
Viewing Angle : 60°
Orientation : Top View
Operating Temperature : -40°C ~ 85°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
77 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Infrared (IR)
Current - DC Forward (If) (Max) : 700mA
Radiant Intensity (Ie) Min @ If : -
Wavelength : 740nm
Voltage - Forward (Vf) (Typ) : 1.9V
Viewing Angle : 120°
Orientation : Top View
Operating Temperature : -40°C ~ 85°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
632 in stock
QT Brightek
Manufacturer : QT Brightek (QTB)
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Color : Blue
Wavelength : 455nm (450nm ~ 460nm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.4V
Lumens/Watt @ Current - Test : 17 lm/W
Current - Max : 700mA
Flux @ Current/Temperature - Test : 20 lm (Typ)
Temperature - Test : 25°C
Viewing Angle : -
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.142" L x 0.142" W (3.60mm x 3.60mm)
Height - Seated (Max) : 0.075" (1.90mm)
0
100 in stock
