Mallory Sonalert Products
- Headquartered in a new 22,000 square foot facility in Indianapolis, Indiana, Mallory Sonalert Products, Inc. is a leader in the manufacture and development of Sonalert® electronic audible signal products. The company has made its trademarked Sonalert line for over thirty years. In addition to sonalert products, Mallory also distributes a full range of audible signal devices including transducers, indicators, sirens, buzzers and related hardware to a broad range of customers in industrial, military and consumer electronic markets.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PF
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 28V
Frequency : 3.5kHz
Technology : Piezo (with Feedback)
Operating Mode : Pulse, Fast
Duration : 3 PPS
Sound Pressure Level (SPL) : 90dB @ 12V, 30cm
Current - Supply : 8mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.181" Dia (30.00mm)
Height - Seated (Max) : 0.638" (16.20mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PF
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 28V
Frequency : 3.5kHz
Technology : Piezo
Operating Mode : Pulse, Fast
Duration : 3 PPS
Sound Pressure Level (SPL) : 90dB @ 12V, 30cm
Current - Supply : 15mA
Port Location : Top
Operating Temperature : -
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.181" Dia (30.00mm)
Height - Seated (Max) : 0.402" (10.20mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PF
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 28V
Frequency : 3.5kHz
Technology : Piezo
Operating Mode : Pulse, Fast
Duration : 3 PPS
Sound Pressure Level (SPL) : 90dB @ 12V, 30cm
Current - Supply : 15mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange
Termination : Wire Leads
Size / Dimension : 1.181" Dia (30.00mm)
Height - Seated (Max) : 0.402" (10.20mm)
0
27 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PF
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 28V
Frequency : 2.9kHz
Technology : Piezo
Operating Mode : Pulse, Fast
Duration : 3 PPS
Sound Pressure Level (SPL) : 90dB @ 12V, 30cm
Current - Supply : 8mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange
Termination : Wire Leads
Size / Dimension : 1.654" Dia (42.00mm)
Height - Seated (Max) : 0.638" (16.20mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PFD
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 24V
Frequency : 3.5kHz
Technology : Piezo
Operating Mode : Pin Selectable
Duration : -
Sound Pressure Level (SPL) : 95dB @ 12V, 30cm
Current - Supply : 10mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange
Termination : Wire Leads
Size / Dimension : 1.102" Dia (28.00mm)
Height - Seated (Max) : 1.000" (25.40mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PFD
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 24V
Frequency : 3kHz
Technology : Piezo
Operating Mode : Pin Selectable
Duration : 3 PPS
Sound Pressure Level (SPL) : 85dB @ 12V, 30cm
Current - Supply : 18mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange
Termination : Wire Leads
Size / Dimension : 0.945" Dia (24.00mm)
Height - Seated (Max) : 0.551" (14.00mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PFD
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 30V
Frequency : 3kHz
Technology : Piezo
Operating Mode : Pin Selectable
Duration : 3 PPS
Sound Pressure Level (SPL) : 80dB @ 12V, 30cm
Current - Supply : 12mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.945" Dia (24.00mm)
Height - Seated (Max) : 0.382" (9.70mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PFD
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 30V
Frequency : 3kHz
Technology : Piezo
Operating Mode : Pin Selectable
Duration : 3 PPS
Sound Pressure Level (SPL) : 80dB @ 12V, 30cm
Current - Supply : 12mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange
Termination : Wire Leads
Size / Dimension : 0.945" Dia (24.00mm)
Height - Seated (Max) : 0.382" (9.70mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PFD
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 24V
Frequency : 3.5kHz
Technology : Piezo
Operating Mode : Pin Selectable
Duration : 3 PPS
Sound Pressure Level (SPL) : 95dB @ 12V, 30cm
Current - Supply : 15mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : Screw Terminal, Quick Connect Tab - 0.189" (4.80mm)
Size / Dimension : 1.437" Dia (36.50mm)
Height - Seated (Max) : 0.933" (23.70mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PFD
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 24V
Frequency : 3.5kHz
Technology : Piezo (with Feedback)
Operating Mode : Pin Selectable
Duration : 3 PPS
Sound Pressure Level (SPL) : 95dB @ 12V, 30cm
Current - Supply : 10mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.181" Dia (30.00mm)
Height - Seated (Max) : 0.638" (16.20mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PFD
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 28V
Frequency : 3.5kHz
Technology : Piezo
Operating Mode : Pin Selectable
Duration : 3 PPS
Sound Pressure Level (SPL) : 90dB @ 12V, 30cm
Current - Supply : 15mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange
Termination : Wire Leads
Size / Dimension : 1.181" Dia (30.00mm)
Height - Seated (Max) : 0.638" (16.20mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : PFD
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 28V
Frequency : 2.9kHz
Technology : Piezo
Operating Mode : Pin Selectable
Duration : 3 PPS
Sound Pressure Level (SPL) : 90dB @ 12V, 30cm
Current - Supply : 8mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange
Termination : Wire Leads
Size / Dimension : 1.654" Dia (42.00mm)
Height - Seated (Max) : 0.638" (16.20mm)
0
100 in stock
