IXYS Integrated Circuits Division
- IXYS Integrated Circuits Division, formerly Clare, Inc., an IXYS Company, designs, manufactures, and markets high-voltage integrated circuits (ICs) and optically isolated Solid State Relays (OptoMOS®) for the communication, industrial, power, and consumer markets.
As a pioneer in the development of Solid State Relays (SSRs), they have become a leading supplier to the telecommunications, security, utility metering, and industrial control industries. IXYS Integrated Circuits Division SSR solutions are rapidly replacing older electromechanical devices in many applications and enhancing overall system performance. They continue to develop leadership products that offer higher levels of integration and electrical performance.
Part Number
Manufacturer
Description
Unit Price
In Stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 3750Vrms
Current Transfer Ratio (Min) : 33% @ 1mA
Current Transfer Ratio (Max) : -
Turn On / Turn Off Time (Typ) : 7µs, 20µs
Rise / Fall Time (Typ) : -
Input Type : AC, DC
Output Type : Transistor with Base
Voltage - Output (Max) : 30V
Current - Output / Channel : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 1mA
Vce Saturation (Max) : 500mV
Operating Temperature : -40°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 6-SMD, Gull Wing
Supplier Device Package : 6-SMD
0
766 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 3750Vrms
Current Transfer Ratio (Min) : 300% @ 1mA
Current Transfer Ratio (Max) : 30000% @ 1mA
Turn On / Turn Off Time (Typ) : 8µs, 345µs
Rise / Fall Time (Typ) : -
Input Type : AC, DC
Output Type : Darlington with Base
Voltage - Output (Max) : 30V
Current - Output / Channel : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 100mA
Vce Saturation (Max) : 1V
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 6-DIP (0.300", 7.62mm)
Supplier Device Package : 6-DIP
0
1285 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 2
Voltage - Isolation : 3750Vrms
Current Transfer Ratio (Min) : 33% @ 1mA
Current Transfer Ratio (Max) : 1000% @ 1mA
Turn On / Turn Off Time (Typ) : 7µs, 20µs
Rise / Fall Time (Typ) : -
Input Type : AC, DC
Output Type : Transistor
Voltage - Output (Max) : 30V
Current - Output / Channel : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 1mA
Vce Saturation (Max) : 500mV
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-DIP
0
332 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 2
Voltage - Isolation : 3750Vrms
Current Transfer Ratio (Min) : 300% @ 1mA
Current Transfer Ratio (Max) : 30000% @ 1mA
Turn On / Turn Off Time (Typ) : 8µs, 345µs
Rise / Fall Time (Typ) : -
Input Type : AC, DC
Output Type : Darlington
Voltage - Output (Max) : 30V
Current - Output / Channel : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 1mA
Vce Saturation (Max) : 1V
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-DIP
0
593 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Tube
Series : -
Part Status : Active
Amplifier Type : Isolation
Number of Circuits : 1
Output Type : -
Slew Rate : -
Gain Bandwidth Product : 10kHz
-3db Bandwidth : -
Current - Input Bias : 340nA
Voltage - Input Offset : -
Current - Supply : -
Current - Output / Channel : -
Voltage - Supply, Single/Dual (±) : -
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-DIP
0
471 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Tube
Alternate Packaging
Series : -
Part Status : Active
Amplifier Type : Isolation
Number of Circuits : 1
Output Type : -
Slew Rate : -
Gain Bandwidth Product : 10kHz
-3db Bandwidth : -
Current - Input Bias : 340nA
Voltage - Input Offset : -
Current - Supply : -
Current - Output / Channel : -
Voltage - Supply, Single/Dual (±) : -
Operating Temperature : -40°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 8-SMD, Gull Wing
Supplier Device Package : 8-SMD
0
170 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Amplifier Type : Isolation
Number of Circuits : 1
Output Type : -
Slew Rate : -
Gain Bandwidth Product : 10kHz
-3db Bandwidth : -
Current - Input Bias : 340nA
Voltage - Input Offset : -
Current - Supply : -
Current - Output / Channel : -
Voltage - Supply, Single/Dual (±) : -
Operating Temperature : -40°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 8-SMD, Gull Wing
Supplier Device Package : 8-SMD
0
995 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Tube
Series : -
Part Status : Active
Amplifier Type : Isolation
Number of Circuits : 1
Output Type : -
Slew Rate : 1 V/µs
Gain Bandwidth Product : 10kHz
-3db Bandwidth : -
Current - Input Bias : 340nA
Voltage - Input Offset : -
Current - Supply : -
Current - Output / Channel : -
Voltage - Supply, Single/Dual (±) : -
Operating Temperature : -40°C ~ 110°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-DIP
0
447 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Tube
Alternate Packaging
Series : -
Part Status : Active
Amplifier Type : Isolation
Number of Circuits : 1
Output Type : -
Slew Rate : 1 V/µs
Gain Bandwidth Product : 10kHz
-3db Bandwidth : -
Current - Input Bias : 340nA
Voltage - Input Offset : -
Current - Supply : -
Current - Output / Channel : -
Voltage - Supply, Single/Dual (±) : -
Operating Temperature : -40°C ~ 110°C
Mounting Type : Surface Mount
Package / Case : 8-SMD, Gull Wing
Supplier Device Package : 8-SMD
0
96 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Amplifier Type : Isolation
Number of Circuits : 1
Output Type : -
Slew Rate : 1 V/µs
Gain Bandwidth Product : 10kHz
-3db Bandwidth : -
Current - Input Bias : 340nA
Voltage - Input Offset : -
Current - Supply : -
Current - Output / Channel : -
Voltage - Supply, Single/Dual (±) : -
Operating Temperature : -40°C ~ 110°C
Mounting Type : Surface Mount
Package / Case : 8-SMD, Gull Wing
Supplier Device Package : 8-SMD
0
996 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 3750Vrms
Current Transfer Ratio (Min) : -
Current Transfer Ratio (Max) : -
Turn On / Turn Off Time (Typ) : -
Rise / Fall Time (Typ) : -
Input Type : DC
Output Type : Photovoltaic, Linearized
Voltage - Output (Max) : -
Current - Output / Channel : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : -
Vce Saturation (Max) : -
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-DIP
0
1907 in stock
IXYS Integrated Circuits Division
Manufacturer : IXYS Integrated Circuits Division
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 3750Vrms
Current Transfer Ratio (Min) : -
Current Transfer Ratio (Max) : -
Turn On / Turn Off Time (Typ) : -
Rise / Fall Time (Typ) : -
Input Type : DC
Output Type : Photovoltaic, Linearized
Voltage - Output (Max) : -
Current - Output / Channel : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : -
Vce Saturation (Max) : -
Operating Temperature : -40°C ~ 85°C
Mounting Type : Surface Mount
Package / Case : 8-SMD, Gull Wing
Supplier Device Package : 8-SMD
0
17308 in stock
