Isocom
- Isocom Components is a leading manufacturer of high performance infrared optoelectronic devices specialising in optocouplers and optoswitches. Since the business was established over 25 years ago Isocom has consistently delivered in excess of there customer's expectations to become one of the most respected brands in the worldwide optoelectronic industry.Expert knowledge and flexible manufacturing processes result in the shortest production lead times in the world for many parts. Product quality and superior customer service is unrivalled and is endorsed by many long-standing customers.
Isocom Components is your natural alternative to all popular commercial optocoupler industry standard types including many no longer supplied by other manufacturers. In addition, they carry out special parametric selections to meet customer's specific circuit design requirements. Parts are available approved to the leading recognized industry standards and all devices are available in various lead forms and in tape and reel packaging if required.
Part Number
Manufacturer
Description
Unit Price
In Stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 3750Vrms
Current Transfer Ratio (Min) : 600% @ 1mA
Current Transfer Ratio (Max) : 7500% @ 1mA
Turn On / Turn Off Time (Typ) : -
Rise / Fall Time (Typ) : 4µs, 3µs
Input Type : DC
Output Type : Darlington
Voltage - Output (Max) : 35V
Current - Output / Channel : 80mA
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Vce Saturation (Max) : 1V
Operating Temperature : -55°C ~ 100°C
Mounting Type : Surface Mount
Package / Case : 4-SMD, Gull Wing
Supplier Device Package : -
0
7559 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 3750Vrms
Current Transfer Ratio (Min) : 50% @ 5mA
Current Transfer Ratio (Max) : 600% @ 5mA
Turn On / Turn Off Time (Typ) : -
Rise / Fall Time (Typ) : 4µs, 3µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 80V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Vce Saturation (Max) : 200mV
Operating Temperature : -55°C ~ 100°C
Mounting Type : Surface Mount
Package / Case : 4-SMD, Gull Wing
Supplier Device Package : 4-SMD
0
200 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Cut Tape (CT)
Alternate Packaging
Series : IS
Part Status : Active
Mounting Type : Surface Mount
Circuit : SPST-NO (1 Form A)
Output Type : AC, DC
Voltage - Input : 1.18VDC
Voltage - Load : 0V ~ 400V
Load Current : 120mA
On-State Resistance (Max) : 30 Ohms
Termination Style : Gull Wing
Package / Case : 6-SMD (0.300", 7.62mm)
Supplier Device Package : 6-SMD
0
100 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Technology : Optical Coupling
Number of Channels : 1
Voltage - Isolation : 5000Vrms
Common Mode Transient Immunity (Min) : 20kV/µs
Propagation Delay tpLH / tpHL (Max) : 200ns, 220ns
Pulse Width Distortion (Max) : 120ns
Rise / Fall Time (Typ) : 35ns, 35ns
Current - Output High, Low : 200mA, 200mA
Current - Peak Output : -
Voltage - Forward (Vf) (Typ) : 1.33V
Current - DC Forward (If) (Max) : 10mA
Voltage - Supply : 4.5 V ~ 30 V
Operating Temperature : -40°C ~ 105°C
Mounting Type : Surface Mount
Package / Case : 6-SOIC (0.268", 6.80mm Width)
Supplier Device Package : 6-SO Stretched
Approvals : -
0
558 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 2
Voltage - Isolation : 5000Vrms
Current Transfer Ratio (Min) : 50% @ 5mA
Current Transfer Ratio (Max) : 400% @ 5mA
Turn On / Turn Off Time (Typ) : 3µs, 2.5µs
Rise / Fall Time (Typ) : -
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 35V
Current - Output / Channel : -
Voltage - Forward (Vf) (Typ) : 1.4V (Max)
Current - DC Forward (If) (Max) : 50mA
Vce Saturation (Max) : 200mV
Operating Temperature : -55°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-DIP
0
1420 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 4
Voltage - Isolation : 5000Vrms
Current Transfer Ratio (Min) : 50% @ 5mA
Current Transfer Ratio (Max) : 400% @ 5mA
Turn On / Turn Off Time (Typ) : -
Rise / Fall Time (Typ) : 15µs, 15µs (Max)
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 35V
Current - Output / Channel : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Vce Saturation (Max) : 200mV
Operating Temperature : -30°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 16-DIP (0.300", 7.62mm)
Supplier Device Package : 16-DIP
0
3162 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 2
Voltage - Isolation : 5300Vrms
Current Transfer Ratio (Min) : 20% @ 10mA
Current Transfer Ratio (Max) : 300% @ 10mA
Turn On / Turn Off Time (Typ) : -
Rise / Fall Time (Typ) : 2.6µs, 2.2µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 50V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Vce Saturation (Max) : -
Operating Temperature : -25°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-DIP
0
1242 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 2
Voltage - Isolation : 5300Vrms
Current Transfer Ratio (Min) : 50% @ 10mA
Current Transfer Ratio (Max) : 400% @ 10mA
Turn On / Turn Off Time (Typ) : -
Rise / Fall Time (Typ) : 2.6µs, 2.2µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 70V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Vce Saturation (Max) : -
Operating Temperature : -25°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-DIP
0
1405 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 2
Voltage - Isolation : 5300Vrms
Current Transfer Ratio (Min) : 12.5% @ 16mA
Current Transfer Ratio (Max) : -
Turn On / Turn Off Time (Typ) : -
Rise / Fall Time (Typ) : 2.6µs, 2.2µs
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 50V
Current - Output / Channel : 50mA
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Vce Saturation (Max) : -
Operating Temperature : -25°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 8-DIP (0.300", 7.62mm)
Supplier Device Package : 8-DIP
0
590 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Cut Tape (CT)
Alternate Packaging
Series : ISP
Part Status : Active
Mounting Type : Surface Mount
Circuit : SPST-NO (1 Form A)
Output Type : AC, DC
Voltage - Input : 1.18VDC
Voltage - Load : 0V ~ 60V
Load Current : 550mA
On-State Resistance (Max) : 2.5 Ohms
Termination Style : Gull Wing
Package / Case : 4-SMD (0.300", 7.62mm)
Supplier Device Package : 4-SMD
0
100 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Cut Tape (CT)
Alternate Packaging
Series : ISP
Part Status : Active
Mounting Type : Surface Mount
Circuit : SPST-NO (1 Form A)
Output Type : AC, DC
Voltage - Input : 1.18VDC
Voltage - Load : 0V ~ 250V
Load Current : 180mA
On-State Resistance (Max) : 15 Ohms
Termination Style : Gull Wing
Package / Case : 4-SMD (0.300", 7.62mm)
Supplier Device Package : 4-SMD
0
100 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Cut Tape (CT)
Alternate Packaging
Series : ISP
Part Status : Active
Mounting Type : Surface Mount
Circuit : SPST-NO (1 Form A)
Output Type : AC, DC
Voltage - Input : 1.18VDC
Voltage - Load : 0V ~ 400V
Load Current : 120mA
On-State Resistance (Max) : 30 Ohms
Termination Style : Gull Wing
Package / Case : 4-SMD (0.300", 7.62mm)
Supplier Device Package : 4-SMD
0
100 in stock
