Isocom
- Isocom Components is a leading manufacturer of high performance infrared optoelectronic devices specialising in optocouplers and optoswitches. Since the business was established over 25 years ago Isocom has consistently delivered in excess of there customer's expectations to become one of the most respected brands in the worldwide optoelectronic industry.Expert knowledge and flexible manufacturing processes result in the shortest production lead times in the world for many parts. Product quality and superior customer service is unrivalled and is endorsed by many long-standing customers.
Isocom Components is your natural alternative to all popular commercial optocoupler industry standard types including many no longer supplied by other manufacturers. In addition, they carry out special parametric selections to meet customer's specific circuit design requirements. Parts are available approved to the leading recognized industry standards and all devices are available in various lead forms and in tape and reel packaging if required.
Part Number
Manufacturer
Description
Unit Price
In Stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 400V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 15mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 6-DIP (0.300", 7.62mm)
Supplier Device Package : 6-DIP
Approvals : UR, VDE
0
761 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 400V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 15mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Surface Mount
Package / Case : 6-SMD, Gull Wing
Supplier Device Package : -
Approvals : UR, VDE
0
873 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 400V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 5mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 6-DIP (0.300", 7.62mm)
Supplier Device Package : 6-DIP
Approvals : UR, VDE
0
1542 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 400V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 5mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Surface Mount
Package / Case : 6-SMD, Gull Wing
Supplier Device Package : -
Approvals : UR, VDE
0
1390 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : No
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 1kV/µs
Current - LED Trigger (Ift) (Max) : 10mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 100µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 6-DIP (0.300", 7.62mm)
Supplier Device Package : -
Approvals : UR, VDE
0
4039 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 30mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 6-DIP (0.300", 7.62mm)
Supplier Device Package : 6-DIP
Approvals : UR, VDE
0
944 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 30mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Surface Mount
Package / Case : 6-SMD, Gull Wing
Supplier Device Package : -
Approvals : UR, VDE
0
2355 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 10mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 6-DIP (0.300", 7.62mm)
Supplier Device Package : 6-DIP
Approvals : UR, VDE
0
977 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 10mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Surface Mount
Package / Case : 6-SMD, Gull Wing
Supplier Device Package : -
Approvals : UR, VDE
0
7077 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 5mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Through Hole
Package / Case : 6-DIP (0.300", 7.62mm)
Supplier Device Package : 6-DIP
Approvals : UR, VDE
0
1896 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Tube
Alternate Packaging
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 5mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Surface Mount
Package / Case : 6-SMD, Gull Wing
Supplier Device Package : -
Approvals : UR, VDE
0
1613 in stock
Isocom Components
Manufacturer : Isocom Components 2004 LTD
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Output Type : Triac
Zero Crossing Circuit : Yes
Number of Channels : 1
Voltage - Isolation : 5300Vrms
Voltage - Off State : 600V
Static dV/dt (Min) : 600V/µs
Current - LED Trigger (Ift) (Max) : 5mA
Current - On State (It (RMS)) (Max) : -
Current - Hold (Ih) : 400µA (Typ)
Turn On Time : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Operating Temperature : -40°C ~ 100°C
Mounting Type : Surface Mount
Package / Case : 6-SMD, Gull Wing
Supplier Device Package : -
Approvals : UR, VDE
0
1455 in stock
