Coto Technology
- Coto Technology is the world leader in Small Signal Switching Solutions, providing high quality products and application design support to customers in a broad range of markets including Automatic Test Equipment, Data Acquisition, Instrumentation, Process Control, Telecommunications, Consumer, Medical and Security markets.
Product lines include Classic Reed Relays, Molded Reed Switches and CotoMOS® Solid State Relays.
Part Number
Manufacturer
Description
Unit Price
In Stock
Coto Technology
Manufacturer : Coto Technology
Packaging : Bulk
Series : FRB
Part Status : Obsolete
Type : Glass Body
Circuit : SPST-NO
Operate Range : 10 ~ 30AT
Release Range : -
Current - Switching : 500mA (AC/DC)
Voltage - Switching AC : 200V
Voltage - Switching DC : 200V
Power - Rated : 10VA
Operate Time : 0.5ms
Release Time : 0.2ms
Mounting Type : Surface Mount
Termination Style : Axial, Flat
Length - Overall : 1.360" (34.54mm)
Size - Body : 0.549" L x 0.100" W x 0.090" H (13.94mm x 2.54mm x 2.29mm)
Height Above Board : -
Operating Temperature : -40°C ~ 125°C
Capacitance : 0.3pF
Current - Carry : 1.5A (AC/DC)
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Packaging : Bulk
Series : FRB
Part Status : Obsolete
Type : Glass Body
Circuit : SPST-NO
Operate Range : 15 ~ 20AT
Release Range : -
Current - Switching : 500mA (AC/DC)
Voltage - Switching AC : 200V
Voltage - Switching DC : 200V
Power - Rated : 10VA
Operate Time : 0.5ms
Release Time : 0.2ms
Mounting Type : Surface Mount
Termination Style : Axial, Flat
Length - Overall : 1.360" (34.54mm)
Size - Body : 0.549" L x 0.100" W x 0.090" H (13.94mm x 2.54mm x 2.29mm)
Height Above Board : -
Operating Temperature : -40°C ~ 125°C
Capacitance : 0.3pF
Current - Carry : 1.5A (AC/DC)
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Packaging : Bulk
Series : FRB
Part Status : Obsolete
Type : Glass Body
Circuit : SPST-NO
Operate Range : 15 ~ 25AT
Release Range : -
Current - Switching : 500mA (AC/DC)
Voltage - Switching AC : 200V
Voltage - Switching DC : 200V
Power - Rated : 10VA
Operate Time : 0.5ms
Release Time : 0.2ms
Mounting Type : Surface Mount
Termination Style : Axial, Flat
Length - Overall : 1.360" (34.54mm)
Size - Body : 0.549" L x 0.100" W x 0.090" H (13.94mm x 2.54mm x 2.29mm)
Height Above Board : -
Operating Temperature : -40°C ~ 125°C
Capacitance : 0.3pF
Current - Carry : 1.5A (AC/DC)
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Packaging : Bulk
Series : FRB
Part Status : Obsolete
Type : Glass Body
Circuit : SPST-NO
Operate Range : 20 ~ 25AT
Release Range : -
Current - Switching : 500mA (AC/DC)
Voltage - Switching AC : 200V
Voltage - Switching DC : 200V
Power - Rated : 10VA
Operate Time : 0.5ms
Release Time : 0.2ms
Mounting Type : Surface Mount
Termination Style : Axial, Flat
Length - Overall : 1.360" (34.54mm)
Size - Body : 0.549" L x 0.100" W x 0.090" H (13.94mm x 2.54mm x 2.29mm)
Height Above Board : -
Operating Temperature : -40°C ~ 125°C
Capacitance : 0.3pF
Current - Carry : 1.5A (AC/DC)
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Packaging : Bulk
Series : HG
Part Status : Discontinued at
Coil Type : -
Coil Current : -
Coil Voltage : 24VDC
Contact Form : SPDT (1 Form C)
Contact Rating (Current) : 2A
Switching Voltage : 500VAC, 500VDC - Max
Turn On Voltage (Max) : -
Turn Off Voltage (Min) : -
Operate Time : -
Release Time : -
Features : -
Mounting Type : Through Hole
Termination Style : PC Pin
Operating Temperature : -
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Series : -
Part Status : Obsolete
Type : Liquid
Output Type : Switch (Single Float)
Output Configuration : SPST-NC/NO
Current : 500mA
Minimum Liquid Specific Gravity : -
Switch Actuation Level : -
Mounting Type : Male 1/2" (12.7mm) NPT
Material - Housing & Prism : Polypropylene (PP)
Operating Temperature : -20°C ~ 85°C
Voltage Rating : 200V
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Series : -
Part Status : Obsolete
Type : Liquid
Output Type : Switch (Single Float)
Output Configuration : SPST-NC/NO
Current : 500mA
Minimum Liquid Specific Gravity : -
Switch Actuation Level : -
Mounting Type : Threaded
Material - Housing & Prism : Polypropylene (PP)
Operating Temperature : -20°C ~ 85°C
Voltage Rating : 200V
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Series : -
Part Status : Obsolete
Type : Liquid
Output Type : Switch (Single Float)
Output Configuration : SPST-NC/NO
Current : 500mA
Minimum Liquid Specific Gravity : -
Switch Actuation Level : -
Mounting Type : Male 1/2" (12.7mm) NPT
Material - Housing & Prism : Acrylonitrile Butadiene Styrene (ABS)
Operating Temperature : -20°C ~ 85°C
Voltage Rating : 200V
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Series : -
Part Status : Obsolete
Type : Liquid
Output Type : Switch (Single Float)
Output Configuration : SPST-NC/NO
Current : 500mA
Minimum Liquid Specific Gravity : -
Switch Actuation Level : -
Mounting Type : Threaded
Material - Housing & Prism : Acrylonitrile Butadiene Styrene (ABS)
Operating Temperature : -20°C ~ 85°C
Voltage Rating : 200V
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Series : -
Part Status : Obsolete
Type : Liquid
Output Type : Switch (Single Float)
Output Configuration : SPST-NC/NO
Current : 500mA
Minimum Liquid Specific Gravity : -
Switch Actuation Level : -
Mounting Type : Male 1/2" (12.7mm) NPT
Material - Housing & Prism : Polyvinylidene Fluoride (PVDF)
Operating Temperature : -20°C ~ 85°C
Voltage Rating : 200V
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Series : -
Part Status : Obsolete
Type : Liquid
Output Type : Switch (Single Float)
Output Configuration : SPST-NC/NO
Current : 500mA
Minimum Liquid Specific Gravity : -
Switch Actuation Level : -
Mounting Type : Male 1/2" (12.7mm) NPT
Material - Housing & Prism : Polypropylene Sulphide (PPS)
Operating Temperature : -20°C ~ 85°C
Voltage Rating : 200V
0
100 in stock
Coto Technology
Manufacturer : Coto Technology
Series : -
Part Status : Obsolete
Type : Liquid
Output Type : Switch (Single Float)
Output Configuration : SPST-NC/NO
Current : 500mA
Minimum Liquid Specific Gravity : -
Switch Actuation Level : -
Mounting Type : Threaded
Material - Housing & Prism : Polypropylene Sulphide (PPS)
Operating Temperature : -20°C ~ 85°C
Voltage Rating : 200V
0
100 in stock
