Bridgelux
- At Bridgelux, we help companies, industries and people experience the power and possibility of light. Since 2002, we’ve designed LED solutions that are high performing, energy efficient, cost effective and easy to integrate. Bridgelux focuses on light’s impact on human behavior, delivering products that create better environments, experiences and returns—both experiential and financial. From our successful Vero® Series to smart lighting, Bridgelux patented technology drives new platforms for commercial and industrial luminaires.
Part Number
Manufacturer
Description
Unit Price
In Stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 18 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 4605 lm (Typ)
Current - Test : 900mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 34.1V
Lumens/Watt @ Current - Test : 150 lm/W
Current - Max : 1.8A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 36.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 18.40mm Diameter
Lens Type : Flat
0
70 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 18 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 6066 lm (Typ)
Current - Test : 1.17A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 34.1V
Lumens/Watt @ Current - Test : 152 lm/W
Current - Max : 2.34A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 18.40mm Diameter
Lens Type : Flat
0
358 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 18 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 5987 lm (Typ)
Current - Test : 1.17A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 34.1V
Lumens/Watt @ Current - Test : 150 lm/W
Current - Max : 2.34A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 36.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 18.40mm Diameter
Lens Type : Flat
0
201 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 18 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 4536 lm (Typ)
Current - Test : 1.05A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 28.3V
Lumens/Watt @ Current - Test : 153 lm/W
Current - Max : 2.1A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 18.40mm Diameter
Lens Type : Flat
0
312 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 18 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 4477 lm (Typ)
Current - Test : 1.05A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 28.3V
Lumens/Watt @ Current - Test : 151 lm/W
Current - Max : 2.1A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 36.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 18.40mm Diameter
Lens Type : Flat
0
58 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 10 Array
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 1090 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 26.7V
Lumens/Watt @ Current - Test : 117 lm/W
Current - Max : 700mA
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 20.00mm W
Height : 1.90mm
Light Emitting Surface (LES) : 9.90mm Diameter
Lens Type : Flat
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 10 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 972 lm (Typ)
Current - Test : 350mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 25.7V
Lumens/Watt @ Current - Test : 108 lm/W
Current - Max : 700mA
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 20.00mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 9.90mm Diameter
Lens Type : Flat
0
290 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 29 Array
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 9450 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 38.6V
Lumens/Watt @ Current - Test : 117 lm/W
Current - Max : 3.15A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : -
Size / Dimension : -
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 8809 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 36.8V
Lumens/Watt @ Current - Test : 114 lm/W
Current - Max : 4.2A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
6970 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 13 Array
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1090 lm (Typ)
Current - Test : 500mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 26.7V
Lumens/Watt @ Current - Test : 116 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : -
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 13 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1773 lm (Typ)
Current - Test : 500mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 31.3V
Lumens/Watt @ Current - Test : 113 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
115 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 13 Array
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1773 lm (Typ)
Current - Test : 500mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 31.3V
Lumens/Watt @ Current - Test : 113 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
100 in stock
