Bridgelux
- At Bridgelux, we help companies, industries and people experience the power and possibility of light. Since 2002, we’ve designed LED solutions that are high performing, energy efficient, cost effective and easy to integrate. Bridgelux focuses on light’s impact on human behavior, delivering products that create better environments, experiences and returns—both experiential and financial. From our successful Vero® Series to smart lighting, Bridgelux patented technology drives new platforms for commercial and industrial luminaires.
Part Number
Manufacturer
Description
Unit Price
In Stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 10032 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 36.8V
Lumens/Watt @ Current - Test : 130 lm/W
Current - Max : 4.2A
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
5548 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 14892 lm (Typ)
Current - Test : 1.8A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 50.7V
Lumens/Watt @ Current - Test : 163 lm/W
Current - Max : 3.6A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
86 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 14854 lm (Typ)
Current - Test : 1.8A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 50.7V
Lumens/Watt @ Current - Test : 163 lm/W
Current - Max : 3.6A
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 49.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
290 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 18863 lm (Typ)
Current - Test : 1.71A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 68.1V
Lumens/Watt @ Current - Test : 162 lm/W
Current - Max : 3.42A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
275 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 18815 lm (Typ)
Current - Test : 1.71A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 68.1V
Lumens/Watt @ Current - Test : 162 lm/W
Current - Max : 3.42A
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 49.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
165 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 12547 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 37.7V
Lumens/Watt @ Current - Test : 158 lm/W
Current - Max : 4.2A
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
1958 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 12516 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 36.6V
Lumens/Watt @ Current - Test : 163 lm/W
Current - Max : 4.2A
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 49.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
2894 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : -
Series : Vero® 13 Array
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 2090 lm (Typ)
Current - Test : 500mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 32.5V
Lumens/Watt @ Current - Test : 140 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 13 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 2037 lm (Typ)
Current - Test : 500mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 31.3V
Lumens/Watt @ Current - Test : 130 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
1623 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 13 Array
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 2037 lm (Typ)
Current - Test : 500mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 31.3V
Lumens/Watt @ Current - Test : 130 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 13 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 2482 lm (Typ)
Current - Test : 450mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 34.1V
Lumens/Watt @ Current - Test : 162 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 70
Viewing Angle : -
Features : With Connector
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
43 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 13 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 2433 lm (Typ)
Current - Test : 450mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 34.1V
Lumens/Watt @ Current - Test : 159 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 70
Viewing Angle : 120°
Features : -
Size / Dimension : 36.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 13.40mm Diameter
Lens Type : Flat
0
94 in stock
