Bridgelux
- At Bridgelux, we help companies, industries and people experience the power and possibility of light. Since 2002, we’ve designed LED solutions that are high performing, energy efficient, cost effective and easy to integrate. Bridgelux focuses on light’s impact on human behavior, delivering products that create better environments, experiences and returns—both experiential and financial. From our successful Vero® Series to smart lighting, Bridgelux patented technology drives new platforms for commercial and industrial luminaires.
Part Number
Manufacturer
Description
Unit Price
In Stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 14726 lm (Typ)
Current - Test : 1.71A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 68.1V
Lumens/Watt @ Current - Test : 126 lm/W
Current - Max : 3.42A
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
113 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 14689 lm (Typ)
Current - Test : 1.71A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 68.1V
Lumens/Watt @ Current - Test : 126 lm/W
Current - Max : 3.42A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : -
Size / Dimension : 49.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
49 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 9796 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 37.7V
Lumens/Watt @ Current - Test : 124 lm/W
Current - Max : 4.2A
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
356 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 9771 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 36.6V
Lumens/Watt @ Current - Test : 127 lm/W
Current - Max : 4.2A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : -
Size / Dimension : 49.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 29 Array
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 2-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 7917 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 37V
Lumens/Watt @ Current - Test : 102 lm/W
Current - Max : 4.2A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 29 Array
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 9060 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 38.6V
Lumens/Watt @ Current - Test : 112 lm/W
Current - Max : 3.15A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : -
Size / Dimension : -
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 8285 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 36.8V
Lumens/Watt @ Current - Test : 107 lm/W
Current - Max : 4.2A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
453 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 13 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1938 lm (Typ)
Current - Test : 450mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 34.1V
Lumens/Watt @ Current - Test : 126 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : With Connector
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
103 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 13 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1899 lm (Typ)
Current - Test : 450mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 34.1V
Lumens/Watt @ Current - Test : 124 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : -
Size / Dimension : 36.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 13.40mm Diameter
Lens Type : Flat
0
56 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 13 Array
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 2-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1575 lm (Typ)
Current - Test : 500mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 31.5V
Lumens/Watt @ Current - Test : 100 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 13 Array
Part Status : Obsolete
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1040 lm (Typ)
Current - Test : 500mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 26.7V
Lumens/Watt @ Current - Test : 111 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : -
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
100 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® 13 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1672 lm (Typ)
Current - Test : 500mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 31.3V
Lumens/Watt @ Current - Test : 107 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 90
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 36.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 13.20mm Diameter
Lens Type : Flat
0
144 in stock
