Bridgelux
- At Bridgelux, we help companies, industries and people experience the power and possibility of light. Since 2002, we’ve designed LED solutions that are high performing, energy efficient, cost effective and easy to integrate. Bridgelux focuses on light’s impact on human behavior, delivering products that create better environments, experiences and returns—both experiential and financial. From our successful Vero® Series to smart lighting, Bridgelux patented technology drives new platforms for commercial and industrial luminaires.
Part Number
Manufacturer
Description
Unit Price
In Stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 10 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1278 lm (Typ)
Current - Test : 270mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 34V
Lumens/Watt @ Current - Test : 139 lm/W
Current - Max : 540mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 30.80mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 9.90mm Diameter
Lens Type : Flat
0
175 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 10 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 1752 lm (Typ)
Current - Test : 360mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 34V
Lumens/Watt @ Current - Test : 143 lm/W
Current - Max : 720mA
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 20.00mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 9.90mm Diameter
Lens Type : Flat
0
160 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 10 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1703 lm (Typ)
Current - Test : 360mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 34V
Lumens/Watt @ Current - Test : 139 lm/W
Current - Max : 720mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 30.80mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 9.90mm Diameter
Lens Type : Flat
0
113 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 10 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 1278 lm (Typ)
Current - Test : 350mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 25.3V
Lumens/Watt @ Current - Test : 144 lm/W
Current - Max : 700mA
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 20.00mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 9.90mm Diameter
Lens Type : Flat
0
243 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 10 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1242 lm (Typ)
Current - Test : 350mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 25.3V
Lumens/Watt @ Current - Test : 140 lm/W
Current - Max : 700mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 30.80mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 9.90mm Diameter
Lens Type : Flat
0
420 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 13585 lm (Typ)
Current - Test : 1.8A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 50.7V
Lumens/Watt @ Current - Test : 149 lm/W
Current - Max : 3.6A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
267 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 13551 lm (Typ)
Current - Test : 1.8A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 50.7V
Lumens/Watt @ Current - Test : 149 lm/W
Current - Max : 3.6A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 49.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
15 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 2-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 17208 lm (Typ)
Current - Test : 1.71A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 68.1V
Lumens/Watt @ Current - Test : 148 lm/W
Current - Max : 3.42A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
7 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 17208 lm (Typ)
Current - Test : 1.71A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 68.1V
Lumens/Watt @ Current - Test : 148 lm/W
Current - Max : 3.42A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
124 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 17165 lm (Typ)
Current - Test : 1.71A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 68.1V
Lumens/Watt @ Current - Test : 147 lm/W
Current - Max : 3.42A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 49.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
19 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Gen 7 Vero® 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 11447 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 37.7V
Lumens/Watt @ Current - Test : 145 lm/W
Current - Max : 4.2A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 49.20mm Diameter
Height : 1.90mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
1088 in stock
Bridgelux, Inc.
Manufacturer : Bridgelux
Packaging : Tray
Series : Vero® SE 29 Array
Part Status : Active
Type : Chip On Board (COB)
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 11418 lm (Typ)
Current - Test : 2.1A
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 36.6V
Lumens/Watt @ Current - Test : 149 lm/W
Current - Max : 4.2A
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 49.20mm Diameter
Height : 3.60mm
Light Emitting Surface (LES) : 29.20mm Diameter
Lens Type : Flat
0
660 in stock
