Alpha and Omega Semiconductor, Inc.
- Alpha and Omega Semiconductor, Inc., or AOS, is a designer, developer and global supplier of a broad range of power semiconductors, including a wide portfolio of Power MOSFET and Power IC products. AOS seeks to differentiate itself by integrating its expertise in device physics, process technology, design and advanced packaging to optimize product performance and cost, and its product portfolio is designed to meet the ever increasing power efficiency requirements in high volume applications, including portable computers, flat panel TVs, battery packs, portable media players and power supplies.
Part Number
Manufacturer
Description
Unit Price
In Stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Type : Low Pass
Filter Order : 2nd
Technology : RC (Pi)
Number of Channels : 6
Center / Cutoff Frequency : 250MHz (Cutoff)
Attenuation Value : -20dB @ 1GHz ~ 3GHz
Resistance - Channel (Ohms) : 100
Current : 20mA
Values : R = 100 Ohms, C = 9pF
ESD Protection : Yes
Operating Temperature : -40°C ~ 85°C
Applications : Data Lines for Mobile Devices
Voltage - Rated : 5V
Mounting Type : Surface Mount
Package / Case : 12-UFDFN Exposed Pad
Size / Dimension : 0.098" L x 0.047" W (2.50mm x 1.20mm)
Height : 0.024" (0.60mm)
0
100 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Type : Low Pass
Filter Order : 2nd
Technology : RC (Pi)
Number of Channels : 8
Center / Cutoff Frequency : 220MHz (Cutoff)
Attenuation Value : -20dB @ 1GHz ~ 3GHz
Resistance - Channel (Ohms) : 100
Current : 20mA
Values : R = 100 Ohms, C = 8pF
ESD Protection : Yes
Operating Temperature : -40°C ~ 85°C
Applications : Data Lines for Mobile Devices
Voltage - Rated : 5V
Mounting Type : Surface Mount
Package / Case : 16-UFDFN Exposed Pad
Size / Dimension : 0.138" L x 0.047" W (3.50mm x 1.20mm)
Height : 0.024" (0.60mm)
0
100 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Type : Low Pass
Filter Order : 2nd
Technology : RC (Pi)
Number of Channels : 4
Center / Cutoff Frequency : 220MHz (Cutoff)
Attenuation Value : -20dB @ 1GHz ~ 3GHz
Resistance - Channel (Ohms) : 100
Current : 20mA
Values : R = 100 Ohms, C = 8pF
ESD Protection : Yes
Operating Temperature : -40°C ~ 85°C
Applications : Data Lines for Mobile Devices
Voltage - Rated : 5V
Mounting Type : Surface Mount
Package / Case : 8-UFDFN Exposed Pad
Size / Dimension : 0.071" L x 0.047" W (1.80mm x 1.20mm)
Height : 0.024" (0.60mm)
0
100 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Type : Low Pass
Filter Order : 2nd
Technology : RC (Pi)
Number of Channels : 6
Center / Cutoff Frequency : 220MHz (Cutoff)
Attenuation Value : -20dB @ 1GHz ~ 3GHz
Resistance - Channel (Ohms) : 100
Current : 20mA
Values : R = 100 Ohms, C = 8pF
ESD Protection : Yes
Operating Temperature : -40°C ~ 85°C
Applications : Data Lines for Mobile Devices
Voltage - Rated : 5V
Mounting Type : Surface Mount
Package / Case : 12-UFDFN Exposed Pad
Size / Dimension : 0.098" L x 0.047" W (2.50mm x 1.20mm)
Height : 0.024" (0.60mm)
0
100 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Steering (Rail to Rail)
Unidirectional Channels : 4
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 5V
Voltage - Breakdown (Min) : 6.6V
Voltage - Clamping (Max) @ Ipp : 16.5V (Typ)
Current - Peak Pulse (10/1000µs) : 5A (100ns)
Power - Peak Pulse : -
Power Line Protection : Yes
Applications : Ethernet, HDMI
Capacitance @ Frequency : 0.8pF @ 1MHz
Operating Temperature : -40°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : SOT-23-6
Supplier Device Package : SOT-23-6
0
9823 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : -
Bidirectional Channels : 1
Voltage - Reverse Standoff (Typ) : 5V (Max)
Voltage - Breakdown (Min) : 6V
Voltage - Clamping (Max) @ Ipp : 22V
Current - Peak Pulse (10/1000µs) : 4A (8/20µs)
Power - Peak Pulse : -
Power Line Protection : No
Applications : General Purpose
Capacitance @ Frequency : 1.25pF @ 1MHz
Operating Temperature : -40°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 0402 (1006 Metric)
Supplier Device Package : 2-DFN (1x0.6)
0
44548 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Zener
Unidirectional Channels : 2
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 5V (Max)
Voltage - Breakdown (Min) : 6V
Voltage - Clamping (Max) @ Ipp : 24V
Current - Peak Pulse (10/1000µs) : 32A
Power - Peak Pulse : -
Power Line Protection : No
Applications : Ethernet, Telecom
Capacitance @ Frequency : 20pF @ 1MHz
Operating Temperature : -40°C ~ 85°C (TJ)
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23-3L
0
5958 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Steering (Rail to Rail)
Unidirectional Channels : 4
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 2.5V (Max)
Voltage - Breakdown (Min) : 2.8V
Voltage - Clamping (Max) @ Ipp : 5V
Current - Peak Pulse (10/1000µs) : 25A (8/20µs)
Power - Peak Pulse : 350W
Power Line Protection : Yes
Applications : Ethernet, Telecom
Capacitance @ Frequency : 3pF @ 1MHz
Operating Temperature : -40°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 10-UFDFN Exposed Pad
Supplier Device Package : 10-DFN (2.6x2.6)
0
4353 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 8
Center / Cutoff Frequency : 450MHz (Cutoff)
Attenuation Value : -25dB @ 800MHz ~ 3GHz
Resistance - Channel (Ohms) : -
Current : -
Values : L = 17nH, C = 16pF
ESD Protection : Yes
Operating Temperature : -40°C ~ 85°C
Applications : Data Lines for Mobile Devices
Voltage - Rated : 5V
Mounting Type : Surface Mount
Package / Case : 16-UFDFN Exposed Pad
Size / Dimension : 0.138" L x 0.047" W (3.50mm x 1.20mm)
Height : 0.024" (0.60mm)
0
100 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 4
Center / Cutoff Frequency : 450MHz (Cutoff)
Attenuation Value : -25dB @ 800MHz ~ 3GHz
Resistance - Channel (Ohms) : -
Current : -
Values : L = 17nH, C = 16pF
ESD Protection : Yes
Operating Temperature : -40°C ~ 85°C
Applications : Data Lines for Mobile Devices
Voltage - Rated : 5V
Mounting Type : Surface Mount
Package / Case : 8-UFDFN Exposed Pad
Size / Dimension : 0.071" L x 0.047" W (1.80mm x 1.20mm)
Height : 0.024" (0.60mm)
0
100 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 6
Center / Cutoff Frequency : 450MHz (Cutoff)
Attenuation Value : -25dB @ 800MHz ~ 3GHz
Resistance - Channel (Ohms) : -
Current : -
Values : L = 17nH, C = 16pF
ESD Protection : Yes
Operating Temperature : -40°C ~ 85°C
Applications : Data Lines for Mobile Devices
Voltage - Rated : 5V
Mounting Type : Surface Mount
Package / Case : 12-UFDFN Exposed Pad
Size / Dimension : 0.098" L x 0.047" W (2.50mm x 1.20mm)
Height : 0.024" (0.60mm)
0
100 in stock
Alpha and Omega Semiconductor, Inc.
Manufacturer : Alpha & Omega Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Steering (Rail to Rail)
Unidirectional Channels : 4
Bidirectional Channels : -
Voltage - Reverse Standoff (Typ) : 3.3V (Max)
Voltage - Breakdown (Min) : 3.5V
Voltage - Clamping (Max) @ Ipp : 8V
Current - Peak Pulse (10/1000µs) : 12A (100ns)
Power - Peak Pulse : -
Power Line Protection : Yes
Applications : HDMI
Capacitance @ Frequency : 0.45pF @ 1MHz
Operating Temperature : -40°C ~ 125°C (TJ)
Mounting Type : Surface Mount
Package / Case : 10-UFDFN
Supplier Device Package : 10-DFN (2.5x1)
0
11996 in stock
